ROG RAMPAGE VI EXTREME OMEGA
specifications summary
(continued on the next page)
LAN
Aquantia AQC-107 10G LAN
Intel
®
I219-V Gigabit LAN
Anti-surge LANGuard
ROG GameFirst Technology
Wireless Data
Network
Intel
®
Wireless-AC 9260
2x2 MU-MIMO 802.11 a/b/g/n/ac support dual frequency band 2.4/5 GHz
Supports channel bandwidth: HT20/HT40/HT80/HT160
Up to 1.73Gbps transfer speed
Bluetooth
Bluetooth v5.0
Audio
ROG SupremeFX 8-Channel High Definition Audio CODEC S1220
- Supports: Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording
input
- SupremeFX Shielding Technology
- ESS
®
SABRE9018Q2C
- Supports up to 32-Bit/192kHz playback*
Audio Features:
- LED-illuminated design
- Optical S/PDIF out port at back Panel
- Sonic Radar III
- Sonic Studio III + Sonic Studio Link
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio.
USB
Intel
®
X299 Chipset
- 6 x USB 3.1 Gen 1 ports (at back panel)
- 4 x USB 2.0 ports (at mid-board)
ASMedia
®
USB 3.1 Gen 2 Controller
- 1 x USB 3.1 Gen 2 front panel connector
- 2 x USB 3.1 Gen 2 ports (1 x Type-A [red] and 1 x Type-C™ ports at back
panel)
ASMedia
®
USB 3.1 Gen 1 Controller
- 8 x USB 3.1 Gen 1 ports (4 at back panel, 4 at mid-board)
