xii
(continued on the next page)
ROG RAMPAGE VI EXTREME OMEGA
specifications summary
Special Features
OC Design
- ASUS PRO Clock II Technology
ASUS Dual Intelligent Processors 5
- 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+
VRM, Fan Expert 4, and Turbo App
AURA:
- Aura Lighting Control
- Aura RGB Strip Headers
- Aura Lighting Effects Synchronization with compatible ASUS ROG devices
- Aura Addressable Strip Header(s)
ASUS Exclusive Features
- USB BIOS Flashback
- MemOK! II
- AI Suite 3
- Ai Charger
- Armoury Crate
- Pre-mounted I/O Shield
- ASUS NODE: hardware control interface
- OptiMem II
- ASUS C.P.R.(CPU Parameter Recall)
- BUPDATER
- BIOS Flashback Button
- Clear CMOS Button
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
ASUS Q-Design
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [green])
- Q-Slot
- Q-DIMM
- Q-Connector
LiveDash
Back Panel I/O
Ports
1 x Clear CMOS button
1 x BIOS Flashback button
1 x 2x2 Wi-Fi Module
1 x Aquantia AQC-107 10G LAN port
1 x Anti-surge LAN (RJ45) ports
2 x USB 3.1 Gen 2 ports (1 x Type-C™ [black] and 1 x Type-A [red])
10 x USB 3.1 Gen 1 ports [blue]
1 x Optical S/PDIF out
5 x LED-illuminated audio jacks
