ASUS RS720-E9-RS24-E
1-5
Model Name RS720-E9-RS24-E
Management
Solution
Out of Band
Remote
Hardware
On-Board ASMB9-iKVM for KVM-over-IP
Software
ASUS Control Center (Classic)
OS Support
Please nd the latest OS support from http://www.asus.com/
Dimension (Depth x Width x
Height)
750 mm x 444 mm x 88 mm (2U)
29.52” x 17.48” x 3.46”
Power Supply
(differentconguration
by region)
1+1 Redundant
800W 80 PLUS Platinum Power Supply (CPU up to 165W)
1200W 80 PLUS Platinum Power Supply (CPU up to 205W)
Rating: 100-127Vac/200-240Vac, 10A/5A, 50/60Hz, Class I
(240Vdc only for China)
850W 80 PLUS Titanium Power Supply (CPU up to 165W)
Rating: 100-127Vac/200-240Vac, 11A/5A, 47-63 Hz
Environment
Operating temperature: 10°C ~ 35°C
Non operating temperature: -40°C ~ 60°C
Non operating humidity: 20% ~ 90% (Non condensing)
*Specicationsaresubjecttochangewithoutnotice.
