Z11PR-D16 specications summary
Model Name Z11PR-D16
Processor Support /
System Bus
2 x Socket P0 (LGA 3647)
1st Gen Intel
®
Xeon
®
Processor Scalable Family
2nd Gen Intel
®
Xeon
®
Processor Scalable Family
UPI 10.4 GT/s
Core Logic
Intel
®
Lewisburg C621 PCH
Form Factor
SSI EEB, 12 in. x 13 in.
ASUS
Features
Fan Speed
Control
Rack Optimized
(Dedicated for
rack)
ASUS Control
Center
Memory
Total Slots
16 (6-channel per CPU, 8 DIMM per CPU)
Voltage
1.2V
Capacity
Maximum up to 4096GB
Memory Type
DDR4 2933* (1 DIMM per Channel)
DDR4 2666/2400/2133 RDIMM/LRDIMM/LRDIMM 3DS
(2 DIMM per Channel)
Intel
®
Optane™ DC persistent memory (DCPMM)
* 2933MHz will drop to 2666MHz when using 2DPC congurations
** Refer to ASUS server AVL for the latest update
Memory Size
4GB, 8GB, 12GB, 32GB (RDIMM)
64GB, 128GB (RDIMM 3DS)
32GB, 64GB, 128GB (LRDIMM)
64GB, 128GB, 256GB (LRDIMM 3DS)
* Refer to ASUS server AVL for the latest update
Expansion
Slots (follow
SSI Location
number)
Total PCI/ PCI-X
/ PCI-E Slots
6+1
Slot Location 1
1 x PCI-E x16 (X16 Gen3 Link)
Slot Location 2
1 x PCI-E x8 (X8 Gen3 Link)
Slot Location 3
1 x PCI-E x8 (X8 Gen3 Link)
Slot Location 4
1 x PCI-E x8 (X8 Gen3 Link)
Slot Location 5
1 x PCI-E x8 (X8 Gen3 Link)
Slot Location 6
1 x PCI-E x16 (X16 Gen3 Link)
Slot Location 7
-
Additional Slot 1
OCP 2.0 module support (X16 Gen3 Link)
Additional Slot 2
-
Networking
LAN
2 x Intel I350-AM2
1 x Management Port
(continued on the next page)
