Daikin FTXV25AV1B [25/40] Introduction to buttons on remote controller
![Daikin ARXV35AV1B [25/40] Introduction to buttons on remote controller](/views2/1772007/page25/bg19.png)
22
Introduction to buttons on remote controller
SAVE function:
Under cool mode, press the SAVE button and the unit will operate under SAVE
mode. The remote controller will display "SE" and the air conditioner will operate at
auto speed. The set temperature can’t be adjusted. Press the SAVE button again to
exit the SAVE mode. The air conditioner will return to the original set speed and set
temperature.
● This function is only applicable to some models.
After pressing this button under cooling or dry mode, the remote controller displays
the "X-FAN" icon and the X-FAN function is started up. Press this button again to
cancel the X-FAN function. The "X-FAN" icon will disappear.
Note:
● After starting up the X-FAN function, when turning off the unit, the indoor fan will
continue to operate for a while at low speed to dry the residual water inside the
indoor unit.
● When the unit operates under the X-FAN mode, press "X-FAN" button to turn off
the X-FAN function. The indoor fan will stop operating immediately.
● At ON status, press this button once to set TIMER OFF. The character of HOUR
and OFF will flash. Press the "+" or "-" button within 5s to adjust the time of TIMER
ON. Each time the "+" or "-" button is pressed, time will increase or decrease by
half an hour. When holding the "+" or "-" button for at least 2s, the time will change
quickly until the required time is reached. After that, press the "TIMER" button
to confirm it. The character of HOUR and OFF won’t flash again. Cancel
TIMER OFF: Press the "TIMER" button again under TIMER OFF status.
● At OFF status, press this button once to set TIMER ON. Please refer to
TIMER OFF for detailed operation.
Cancel TIMER ON: Press the "TIMER" button again under TIMER ON status.
Note:
● Time setting range: 0.5-24 hours.
● Time interval between two operations can’t exceed 5s, otherwise the remote
controller will exit the setting status automatically.
● The TIMER OFF function is resetted when the CHILD LOCK function is unlocked.
6
SAVE button
7
X-FAN button
8
TIMER button
