Base Mounted Turbine Pumps
3
6C
www.cranepumps.com
Series: EC & ED
Dimensions - Pump Only
1/06
DIMENSIONS IN INCHES (mm)
PUMP A B CP D E F G H K L M N P R U W X Y Suc. Dis.
EC 7
(177)
5¼
(133)
20⅛
(511)
4½
(114)
2
15
⁄
16
(74)
3¼
(82)
½
(13)
9
⁄
16
(14)
1¾
(44)
7
7
⁄
16
(188)
5
3
⁄
16
(131)
2⅜
(60)
1
(25)
6
13
⁄
16
(173)
¾
(19)
1⅛
(28)
4½
(114)
2
9
⁄
16
(65)
1½
NPT
1¼
NPT
ED 7
(177)
5¼
(133)
25
3
⁄
16
(639)
5¼
(133)
2
15
⁄
16
(74)
3¼
(82)
½
(13)
9
⁄
16
(14)
1¾
(44)
9
(228)
7
1
⁄
16
(179)
3⅛
(79)
1
(25)
9¼
(234)
1⅛
(28)
½
(13)
5¼
(133)
2
15
⁄
16
(74)
2½
NPT
2
NPT
A strainer, approximately 20 mesh, should be installed on the suction side of the pump to prevent chips,
scale or hard foreign particales from entering the pump and damaging the raceway and impeller.
