Model No.DLM382 380MM CORDLESS LAWN MOWER

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

󳢢󳢢󳢢󳢢C10 263005-3 RUBBER PIN 6 4

󳢢󳢢󳢢󳢢D10 INC. 39

042 266326-2 TAPPING SCREW 4X18 3

043 127393-1 COWLING M ASSEMBLY 1

󳢢󳢢󳢢󳢢D10 INC. 45-48

044 266326-2 TAPPING SCREW 4X18 4

045 453250-0 LOCK LEVER 1

046 233173-6 COMPRESSION SPRING 4 1

047 453251-8 LOCK LEVER SUPPORT 1

048 266326-2 TAPPING SCREW 4X18 2

049 620B91-3 LED CIRCUIT 1

050 455070-8 LED COVER 1

051 266326-2 TAPPING SCREW 4X18 2

052 629A17-6 DC MOTOR 1

053 266774-5

+ PAN HEAD SCREW M6X30

WITH WR

054 265999-8 TAPPING SCREW 4X25 2

055 687124-5 STRAIN RELIEF 1

056 266326-2 TAPPING SCREW 4X18 2

057 638946-6 LEAD UNIT 1

058 688162-0 LINE FILTER 1

059 688165-4 LINE FILTER 2

060 632P17-7 CONTROLLER UNIT 1

󳢢󳢢󳢢󳢢C10 654208-4 RECEPTACLE 1

󳢢󳢢󳢢󳢢D10 INC. 61

061 688162-0 LINE FILTER 1

062 459811-4 BLADE SUPPORT 1

063 191D41-2 BLADE 380 SET 1

064 256933-9

HEX. HEAD BOLT M8X35 WITH

065 140S15-0 REAR FLAP COMPLETE 1

󳢢󳢢󳢢󳢢D10 INC. 29

066 LC961018-5 STOP RING (EXT) E-5 2

067 259068-5 ROD 6 1

068 LC233597-6 TORSION SPRING 8 1

070 459777-8 DECK 1

󳢢󳢢󳢢󳢢C10 346544-9 PLATE NUT M8 2

󳢢󳢢󳢢󳢢C20 931302-2 HEX. NUT M6 3

071 412272-9 UNDER COVER 1

072 266326-2 TAPPING SCREW 4X18 3

073 LC231875-8 TENSION SPRING 16 1

074 266326-2 TAPPING SCREW 4X18 1

075 LC267102A7 FLAT WASHER 4 1

Please order the parts with part number. Print Date 26/3/2020
