Makita DLM382PM2 [7/7] Model no dlm382 380mm cordless lawn mower

Model No.DLM382 380MM CORDLESS LAWN MOWER

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

076 LC231297-2 COMPRESSION SPRING 9 1

077 LC253808A3 FLAT WASHER 9 1

078 266326-2 TAPPING SCREW 4X18 2

079 931302-2 HEX. NUT M6 1

080 LC257670A8 SLEEVE 6 1

081 453255-0 ADJUST PLATE 1

082 459099-6 CHANGE LEVER 1

083 LC921352-5 HEX.BOLT M6X30 1

084 347571-9 CONNECTING ROD 1

085 LC941101-4 FLAT WASHER 5 2

086 252103-8 HEX. LOCK NUT M5-8 2

087 LC252145-2 COLLARED HEX. NUT M8 2

088 459101-5 REAR WHEEL 2

089 LC210070-3 BALL BEARING 6200ZZ 2

090 162683-5 REAR SHAFT 1

091 LC346545-7 PLATE 2

092 266326-2 TAPPING SCREW 4X18 2

093 LC252145-2 COLLARED HEX. NUT M8 2

094 459100-7 FRONT WHEEL 2

095 LC210070-3 BALL BEARING 6200ZZ 2

096 162682-7 FRONT SHAFT 1

097 341462-6 PLATE 2

098 266326-2 TAPPING SCREW 4X18 4

099 327411-7 REAR BAG ROD 1

100 267438-4 FLAT WASHER 5 2

101 266326-2 TAPPING SCREW 4X18 2

102 127392-3 REAR BAG ASSEMBLY M 1

󳢢󳢢󳢢󳢢D10 INC. 104-108

104 273676-8 GRIP B 1

105 459812-2 REAR BAG COVER 1

106 266326-2 TAPPING SCREW 4X18 2

107 162684-3 REAR BAG 1

108 459806-7 INDICATOR M 1

A01 782016-4 OFFSET WRENCH 13 1

A02B ***DC18SH DC18SH TWO PORT CHAGER 1

󳢢󳢢󳢢󳢢D10 COMPO-PARTS

A03B 197280-8 BATTERY BL1850B SET 2

E01 819M64-9 SOUND 91DB LABEL 1

Please order the parts with part number. Print Date 26/3/2020
