Daikin RXS60BVMB [14/340] External appearance
![Daikin RXS60BVMB [14/340] External appearance](/views2/1773521/page14/bge.png)
Si21-205A Models
Model Name and Power Supply 3
1.2 External Appearance
Indoor Units
Remote Controller
Outdoor Units
FFQ-B
FHQ-BU
Wireless Type
Wired Type
25/35 Class
50/60 Class
