8.3 Capacity Correction Factor by the Length of Refrigerant Piping (Reference)
The cooling and the heating capacity of the unit has to be corrected in accordance with the length of
refrigerant piping. (The distance between the indoor unit and the outdoor unit)
Split System < — line : Cooling Capacity>
< --- line : Heating Capacity>
Capacity correction factor
1
5101520 3025
0.9
0.8
Cooling / Heating (R22)
Piping length (m)
(R2593)
Range of the Refrigerant Additional Charge
