Daikin FTKD50BVMA [77/85] Optional accessories
![Daikin FTKD50BVMA [77/85] Optional accessories](/views2/1773567/page77/bg4d.png)
2SWLRQDO$FFHVVRULHV ('
5RRP$LU&RQGLWLRQHUV%6HULHV
14.Optional Accessories
14.1 Option List
Notes: ★
1 Wiring adaptor is also required for each indoor unit.
★
2 Wiring adaptor ; Supplied by DAIKIN. Time clock and other devices ; Field supply.
Option Name Kit Name Applicable Model
1 Centralized Control Board-Up to 5 Rooms
★1 KRC72 Indoor Unit
2
Wiring Adaptor for Time Clock / Remote Control
★2
(Normal Open Pulse Contact / Normal Open Contact)
KRP413A1S Indoor Unit
3 Central Remote Controller
★1 DCS302B61 Indoor Unit
4 Unified ON/OFF Controller
★1 DCS301B61 Indoor Unit
5 Schedule Timer Controller
★1 DST301B61 Indoor Unit
6 Interface Adaptor for Room Air Conditioner
★2 KRP928A2S Indoor Unit
7 Air Purifying Filter with Photocatalytic Deodorizing Function KAF952A42 Indoor Unit
8 The Remote Controller Loss Prevention with the Chain KKF917A4 Indoor Unit
9 Drain Plug KKP937A4 Outdoor Unit
10 Air Direction Adjustment Grille KPW945A4 Outdoor Unit
