Daikin RYS60BVMB [5/53] Specifications
![Daikin RYS60BVMB [5/53] Specifications](/views2/1773511/page5/bg5.png)
ELECTRICAL DATA
RS+FCQ50B
RS+FCQ60B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FCQ50B7V1 RS50BVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 78 7.38 53 0.18 45 0.6
FCQ60B7V1 RS60BVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 89 8.72 53 0.24 45 0.6
3TW25081-2
RS+FFQ50B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FFQ RS 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 72 7.43 53 0.18 55 0.7
3D041020
RS+FFQ60B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FFQ RS 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 85 8.45 53 0.24 55 0.7
3D041020
RS+FBQ50B
RS+FBQ60B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FBQ50B7V1 RS50BVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 75 7.00 53 0.18 85 0.7
FBQ60B7V1 RS60BVMB 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 91 8.96 53 0.24 125 0.9
3TW25081-2
RS+FHQ50B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FHQ RS 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
15 15 78 4.91 19 0.35 62 0.6
3D040602
RS+FHQ60B
Indoor unit Outdoor unit
Power supply Compressor OFM IFM
Hz-Volts
Voltage range
MCA MFA RHz RLA W FLA W FLA
FHQ RS 50-230
MAX. 50Hz 253V
MIN. 50Hz 207V
18 20 79 7.5 53 0.18 62 0.6
3D040605
SYMBOLS
MCA : Min. Circuit Amps (A)
MFA : Max. Fuse Amps (A)
RHz : Rated operating frequency(Hz)
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps
W : Rated motor output (W): Rated motor output (W)
NOTES
1. RLA is based on the following conditions:
Indoor temp.: 27°CDB/19.0°CWB
Outdoor temp. : 35°CDB
2. Maximum allowable voltage unbalance between phases is 2%
3. Select wire size based on the larger value of MCA.
4. Instead of fuse, use circuit breaker.
5. For more details concerning conditional connections, see
http://www.daikineurope.com/extranet, select ’’Daikin Documentation’’
and select ’’conditional connection’’, ’’the requested product type’’ and
’’English’’ from the drop down lists, click the search button.
Finally, click on the document title of your choice.
•
Pair Application •
R-410A •
RN20,25,35CVMB • RS50,60BVMB
2
Specifications
26
2
461
• Split - Sky Air • Outdoor Units
