![Daikin RKS35CVMB [31/246] Specifications](/views2/1773639/page31/bg1f.png)
Specifications SiENBE04-401A
22 Specifications
50Hz 230V
Note: MAX. interunit piping length: 20m
MAX. interunit height difference: 15m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
The data are based on the conditions shown in the table below.
Models
Indoor Units ATXS20CVMB(9) ATXS25CVMB(9)
Outdoor Units
ARXS20CVMB ARXS25CVMB
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.0 (1.3~3.0) 2.7 (1.3~4.5) 2.5 (1.3~3.0) 3.4 (1.3~4.5)
Btu/h 6,800 (4,450~10,250) 9,200 (4,450~15,350) 8,550 (4,450~10,250) 11,600 (4,450~15,350)
kcal/h 1,720 (1,120~2,580) 2,320 (1,120~3,870) 2,150 (1,120~2,580) 2,920 (1,120~3,870)
Moisture Removal L/h 0.9 — 1.2 —
Running Current (Rated) A 2.8 3.5 3.9 4.4
Power Consumption
Rated (Min.~Max.)
W 500 (300~980) 675 (290~1,460) 695 (300~980) 935 (290~1,460)
Power Factor % 79.6 82.1 79.3 93.7
COP (Rated) W/W 4.00 4.00 3.60 3.64
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ18.0 φ18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units ATXS20CVMB(9) ATXS25CVMB(9)
Front Panel Color White White
Air Flow Rate
mł/min
(cfm)
H 7.7 (272) 7.8 (275) 7.7 (272) 7.8 (275)
M 5.9 (208) 6.5 (230) 5.9 (208) 6.5 (230)
L 4.2 (148) 5.3 (187) 4.2 (148) 5.3 (187)
SL 3.6 (127) 4.6 (162) 3.6 (127) 4.6 (162)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185
Packaged Dimensions (H×W×D) mm 258×834×325 258×834×325
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 38 / 32 / 25 / 22 38 / 33 / 28 / 25 38 / 32 / 25 / 22 38 / 33 / 28 / 25
Sound Power H dBA 56 56 56 56
Outdoor Units ARXS20CVMB ARXS25CVMB
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23NXD#A 1YC23NXD#A
Motor Output W 600 600
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 0.80 0.80
Air Flow Rate mł/min (cfm)
H 34 (1,201) 30.6 (1,080) 34 (1,201) 30.6 (1,080)
L 24.8 (876) 24.7 (872) 24.8 (876) 24.7 (872)
Fan
Type Propeller Propeller
Motor Output W 31 31
Running Current (Rated) A 2.62 3.32 3.72 4.22
Power Consumption (Rated) W 460 635 655 895
Power Factor % 76.3 83.2 76.6 92.2
Starting Current A 3.5 4.4
Dimensions (H×W×D) mm 550×765×285 550×765×285
Packaged Dimensions (H×W×D) mm 589×882×363 589×882×363
Weight kg 30 30
Gross Weight kg 35 35
Operation
Sound
H/L dBA 46 / 43 47 / 44 46 / 43 47 / 44
Sound Power H dBA 61 62 61 62
Drawing No. 3D044251B 3D044252B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=mł/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
