Daikin RYN20CVMB [178/246] Disengage a hook from the backward
![Daikin FTXS35CAVMB [178/246] Disengage a hook from the backward](/views2/1774119/page178/bgb2.png)
SiENBE04-401A Indoor Unit
Removal Procedure 169
6
Disengage a hook from
the backward.
7
Since the fan bearing is
made of rubber, push it
strongly off from the
inside. The bearing can
be removed just as the
left side plate is
attached with.
Step Procedure Points
Left-side
plate
(R2564)
Bearing
(R2565)
