Outdoor Unit / RK(X)H-C, ARK(X)H-C, R(Y)N-C SiENBE04-401A
192 Removal Procedure
5
The front panel and the
left side panel can be
separated when the
fixing screw is removed.
Sectional view at the front.
Step Procedure Points
(R4105)
Top panel
The edge of the top panel
gets into this groove.
Left side
panel
