Vitek VT-3210 Инструкция по эксплуатации онлайн
MANUAL INSTRUCTION
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ
PORTABLE RADIO CASSETTE RECORDER
ОДНОКАССЕТНАЯ МАГНИТОЛА
МОДЕЛЬ VT%3210
3210.qxd 27.06.03 17:49 Page 2
Содержание
- Модель vt 3210 1
- English 2
- Гарантийный талон 2
- Купон 1 2
- Купон 2 2
- Купон 3 2
- English 3
- Portable radio cassette recorder 3
- Ac operation insert end of the ac power cord into an ac wall outlet the batteries will be automatically disconnected 4
- Cassette operation 4
- Control operation and function 4
- Dc operation open the battery door 20 install 6 pcs um 1 size batteries please make sure they are inserted with correct polarity and close the door your unit is now ready for operation 4
- English 4
- Fm stereo indicator 5 when the unit is turned on this led indicator will illuminate 4
- Insertion and removal of cassette tape a for insertion of cassette tape depress the stop eject button 14 to open the cassette door insert a good quality music recorded cassette tape open part of cassette facing downwards and firmly dose the cassette door b for removal of cassette tape turn off the tape operation by pressing firmly stop eject button 14 and pressing once again to open the cassette door then slide out the cassette tape 4
- Mic recording a install a cassette tape b place function switch 10 to tape position c depress record button 18 and play button 17 simultaneously recording then starts through the built in condenser microphone 3 d to end recording press stop eject button 14 or it will automatically stop when the cassette runs to the very end 4
- Playback a set function switch 10 to tape position b insert recorded tape of your favorite music c press play button 17 firmly down until locked and enjoy your favorite music d adjust volume control 8 to desired level e press fast fordward button 15 firmly in case you want to forward tape f press rewind button 16 firmly in case you want to rewind tape g when tape comes to an end in play mode tape playback will be automatically switched off 4
- Power supply this unit is designed to operate on ac mains supply or 9v dc by using 6 pieces um 1 size or equivalent batteries batteries not included 4
- Qxd 27 6 3 17 49 page 8 4
- Radio operation a set function switch 10 to radio position and set band switch 11 to your desired radio band position b tune in to your desired radio station with the tuning knob 12 c adjust volume control 8 to desired output level d extend telescopic antenna 9 to full extent if you are listening to fm broadcasting e turn off the radio by switching function switch 10 to tape position 4
- Radio recording a install a cassette tape b place function switch 10 to radio position after selecting the desired band and tune the tuning knob 12 to desired broadcast station then push down record button 18 and play 4
- Русский 4
- Button 17 simultaneously c after recording the desired broadcast depress the stop eject button 14 lightly and then place function switch 10 to tape position in order to listen to the recorded broadcast d if you desire to play recorded broadcast please follow the instructions explained in playback section 5
- English русский 5
- Headphone jack 7 for private listening insert a 3 mm headphone not included into the headphone jack 7 the speaker 1 output is automatically cut off caution listening at high power for along moment could damage users ears erasure when you record over previously recorded tape the original recording is automatically erased and replaced by this newly recording materials 5
- Precautions and maintenance a avoid placing this unit near sources of high temperature such as fireplace or sunlight for long time as this may result in damages to plastic housing or electrical parts inside the unit b if you are not using the unit for an extended period of time please remove batteries as batteries may leak and cause damages c be sure to press stop button 14 before inserting or removing cassette tape d as playback head might get oxidized after certain time of use this can be cleaned with cotton swab or q tip dipped in alcohol e there are no serviceable parts inside the unit therefore do not open back cover of unit in case of any defect or repair of unit please refer to qualified service centre 5
- Qxd 27 6 3 17 49 page 10 5
- Service life of the portable radio cassette recorder not less than 3 years 5
- Specifications general power requirement ac 220v dc 9v um 1 x 6 pcs power consumption ac 8 watts weight approx kg dimensions 370mm w x 160mm h x 140mm d operation temperature 5 c 35 c receiver section receivingbands am 540 1600khz fm1 64 87 mhz fm2 88 108 mhz cassette section recording system 2 tracks 2 channel stereo biasing system magnet erase frequency response 125 5 khz wow and flutter 0 5 wrms jis audio section power output maximum 1 watt сhannel 10 thd 1 watt channel speaker impedance 4 ohm x 2 buzzer 2 pcs headphone impedance 4 32 ohms accessories instruction booklet 1 output power 1 w x 2 rms output power 200 w p m p o 5
- Динамики 2 ручка магнитолы 3 встроенный микрофон 4 шкала настройки радио 5 индикатор fm стерео 6 кассетоприемник 7 гнездо для подключения наушников 8 регулятор громкости 9 антенна 10 функциональный переключатель 11 переключатель диапазонов 12 регулятор настройки радио 6
- Кнопка пауза 14 кнопка стоп выброс кассеты 15 кнопка ускоренной перемотки вперед 16 кнопка ускоренной перемотки назад 17 кнопка воспроизведение 18 кнопка запись 19 высокочастотные динамики 20 отсек для батареек 21 гнездо для подключения сетевого шнура 6
- Русский 6
