MANUAL INSTRUCTION
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ
RADIO CASSETTE RECORDER
ОДНОКАССЕТНАЯ МАГНИТОЛА
МОДЕЛЬ VT#3207
3207.qxd 28.10.03 13:10 Page 2
Содержание
- Модель vt 3207 1
- English 2
- Гарантийный талон 2
- Купон 1 2
- Купон 2 2
- Купон 3 2
- English 3
- Ac operation insert one end of the ac power cord into ac socket of the set and the other end into an ac wall out let the batteries will be automatically disconnected 4
- Cassette operation 4
- Control operation and function 4
- Dc operation open the battery door install 4 pcs um 1 size batteries please make sure they are inserted with correct polarity and close the door your unit is now ready for operation 4
- English 4
- Insertion and removal of cassette tape a for insertion of cassette tape depress the stop eject button to open the cassette door insert a good quality music recorded cassette tape open part of cassette facing upwards and firmly close the cassette door b for removal of cassette tape turn off the tape operation by pressing firmly stop eject but ton and press once again to open the cassette door then slide out the cassette tape 4
- Playback a set function switch to tape position b insert recorded tape of your favorite music c press play button firmly down until locked and enjoy your favorite music d adjust volume control to desired level e press fast fordward button firmly in case you want to forward tape f press rewind button firmly in case you want to rewind tape g when tape comes to an end in play mode tape playback will be automatically switched off 4
- Power supply this unit is designed to operate on ac mains supply or 6v dc by using 4 pieces um 1 size or equiv alent batteries batteries not included 4
- Qxd 28 0 3 13 10 page 8 4
- Radio operation a set function switch to radio position and set band switch to your desired radio band position b tune in to your desired radio station with the tuning knob c adjust volume control to desired output level d extend telescopic antenna to full extent if you are listening to fm or am broadcasting e turn off the radio by switching function switch to tape position 4
- Speaker connections 1 place the pair of speakers on the right and left side of the set 2 join the speakers to the main unit by positioning the two hooks of the speaker boxes into the sliding edges of the main unit then pull down until the speakers are locked into position 3 once the speakers have been locked into position connect the left and the right speaker plugs into rear speaker jacks according to the correct marking 4 to detach the speakers from main unit pull up the speaker little while pushing the speaker release locks warning speakers must be plugged into the jacks firmly before switch on the power of unit 4
- Русский 4
- Спецификация питание ac220в 50гц dc 6v um 1 d x 4 частотные диапазоны fm1 64 88 mгц fm2 88 108 mгц am 540 1600 kгц колонки 8 ом наушники 32 ом выходная мощность 5 вт rms 300 вт p m p o частота воспроизведения 125 5 кгц 4
- Срок службы магнитолы не менее 3 х лет 4
- Чистка головок для обеспечения нормальной работы магнитофона регулярно чистите лентопротяжный механизм прижимной резиновый ролик магнитные головки направляющие валики и стойки чистку следует производить тампоном смоченным в спирте или специальной жидкости не используйте для чистки ворсистые ткани любые абразивные материалы и растворители загрязнение механизма зависит от качества магнитной ленты поэтому используйте только кассеты известных производителей 4
- Эквалайзер с помощью трех частотных регуляторов вы можете изменять качество звука регулируемые частоты 100 гц 1кгц 10 кгц 4
- English русский 5
- Graphic equalizer version 1 graphic equalizer is a device by which you can change tone equality of sound by compen sating its frequency characteristic the frequencies are 100hz 1khz and 10khz 2 by controlling the levels of each range sound and frequency characteristic desired effect may be reproduced 5
- Headphone jack for private listening insert a 3 mm headphone not included into the headphone jack the speaker output is automatically cut off caution listening at high power for along moment could damage users ears erasure when you record over previously recorded tape the original recording is automatically erased and replaced by this newly recording material 5
- Mic recording a install a cassette tape b place function switch to tape position c depress record button and play button simultaneously recording then starts through the built in condenser microphone d to end recording press the stop eject button or it will automatically stop when the cas sette runs to the very end 5
- Precautions and maintenance a avoid placing this unit near sources of high temperature such as fireplace or sunlight for long time as this may result in damages to plastic housing or electrical parts inside the unit b if you are not using the unit for an extended period of time please remove batteries as batter ies may leak and cause damages c be sure to press stop button before inserting or removing cassette tape d as playback head might get oxidized after certain time of use this can be cleaned with cotton swab or q tip dipped in alcohol e there are no serviceable parts inside the unit therefore do not open back cover of unit in case of any defect or repair of unit please refer to qualified service center 5
- Radio recording a install a cassette tape b place function switch to radio position after selecting the desired band and tune the tuning knob to desired broadcast station then push down record button and play button simultaneously c after recording the desired broadcast depress the stop eject button lightly and then place function switch to tape position in order to listen to the recorded broadcast d if you desire to play recorded broadcast please follow the instructions explained in playback column 5
- Service life of the radio cassette recorder not less than 3 years 5
- Specifications power supply ac 220v 50hz dc 6v um 1 d x 4 radio frequence coverage fm1 64 88 mhz fm2 88 108 mhz am 540 1600 khz terminal impedans speakers 8 ohms headphone 32 ohms frequency response 125 5 khz output power 5 w rms 300 w p m p o 5
- Динамики 2 дисплей 3 функциональный переключатель 4 встроенный микрофон 5 переключатель частот 6 шкала настройки 7 регулятор настройки 8 регулятор громкости 9 ручка магнитолы 10 отсек для кассеты 11 кнопка запись 12 кнопка воспроизведение 13 кнопка ускоренной перемотки назад 6
- Кнопка ускоренной перемотки вперед 15 кнопка стоп выброс кассеты 16 кнопка пауза 17 отсек для батареек 18 антенна 19 гнездо для подключения сетевого шнура 20 гнёзда для подключения динамиков 21 гнездо для подключения наушников 22 крепления для колонок 23 графические эквалайзеры 6
- Расположение элементов управления 6
- Русский 6
