9
CONTROL OPERATION AND FUNCTION
• POWER SUPPLY
This unit is designed to operate on AC mains supply or 6V DC by using 4 pieces UM1 size or equiv
alent batteries. (Batteries not included)
• AC OPERATION
Insert one end of the AC power cord into AC socket of the set and the other end into an AC wall out
let. The batteries will be automatically disconnected.
• DC OPERATION
Open the BATTERY DOOR. Install 4 pcs UM1 size batteries. Please make sure they are inserted
with correct polarity and close the door. Your unit is now ready for operation.
• SPEAKER CONNECTIONS
1. Place the pair of speakers on the right and left side of the set.
2. Join the speakers to the main unit by positioning the two hooks of the speaker boxes into the
sliding edges of the main unit. Then pull down until the speakers are locked into position.
3. Once the speakers have been locked into position. Connect the left and the right speaker plugs
into rear SPEAKER JACKS according to the correct marking.
4. To detach the speakers from main unit, pull up the speaker little while pushing the “SPEAKER
RELEASE LOCKS”.
WARNING: Speakers must be plugged into the jacks firmly before switch on the power of unit.
• RADIO OPERATION
A. Set FUNCTION SWITCH to "RADIO" position and set BAND SWITCH to your desired radio band
position.
B. Tune in to your desired radio station with the TUNING knob.
C. Adjust VOLUME CONTROL to desired output level.
D. Extend TELESCOPIC ANTENNA to full extent if you are listening to FM or AM broadcasting.
E. Turn off the radio by switching FUNCTION SWITCH to "TAPE" position.
CASSETTE OPERA
TION
• INSERTION AND REMOVAL OF CASSETTE TAPE
A. For insertion of cassette tape: depress the STOP/EJECT BUTTON to open the cassette door.
Insert a good quality music recorded cassette tape (open part of cassette facing upwards) and
firmly close the cassette door.
B. For removal of cassette tape: turn off the tape operation by pressing firmly STOP/EJECT BUT
TON and press once again to open the cassette door. Then slide out the cassette tape.
• PLAYBACK
A. Set FUNCTION SWITCH to "TAPE" position.
B. Insert recorded tape of your favorite music.
C. Press PLAY BUTTON firmly down until locked and enjoy your favorite music.
D. Adjust VOLUME CONTROL to desired level.
E. Press FAST FORDWARD BUTTON firmly in case you want to forward tape.
F. Press REWIND BUTTON firmly in case you want to rewind tape.
G. When tape comes to an end in play mode, tape playback will be automatically switched off.
4
ENGLISH
ЭКВАЛАЙЗЕР
С помощью трех частотных регуляторов вы можете изменять качество звука. Регулируемые
частоты: 100 Гц, 1КГц, 10 КГц.
ЧИСТКА ГОЛОВОК
Для обеспечения нормальной работы магнитофона регулярно чистите лентопротяжный механизм
( прижимной резиновый ролик, магнитные головки, направляющие валики и стойки). Чистку
следует производить тампоном, смоченным в спирте или специальной жидкости. Не используйте
для чистки ворсистые ткани, любые абразивные материалы и растворители.
Загрязнение механизма зависит от качества магнитной ленты, поэтому используйте только
кассеты известных производителей.
СПЕЦИФИКАЦИЯ
Питание AC220В/50Гц; DC 6V UM1(D) x 4;
Частотные диапазоны FM1 6488 MГц ; FM2 88108 MГц ; AM 5401600 KГц ;
Колонки 8 Ом
Наушники 32 Ом
Выходная мощность 5 Вт (RMS); 300 Вт (P.M.P.O.)
Частота воспроизведения 125 ~ 5 КГц
СРОК СЛУЖБЫ МАГНИТОЛЫ НЕ МЕНЕЕ 3Х ЛЕТ
УСЛОВИЯ ГАРАНТИЙНОГО ОБСЛУЖИВАНИЯ
Уважаемый покупатель!
Фирма VITEK выражает благодарность за Ваш выбор и гарантирует высокое качество и безупречное
функционирование приобретенного Вами изделия при соблюдении правил его эксплуатации.
Срок гарантии на все изделия - 12 месяцев со дня покупки. Данным гарантийным талоном VITEK
подтверждает исправность данного изделия и берет на себя обязательство по бесплатному устранению
всех неисправностей, возникших по вине производителя.
Гарантийный ремонт может быть произведен в авторизированном сервис-центре на территории
России.
Условия гарантии:
1. Настоящая гарантия имеет силу при соблюдении следующих условий:
- правильное и четкое заполнение гарантийного талона с указанием наименования модели, ее
серийного номера, даты продажи и печати фирмы-продавца в гарантийном талоне и отрывных купонах;
- наличие оригинала квитанции (чека), содержащего дату покупки.
2. VITEK оставляет за собой право на отказ в гарантийном обслуживании в случае непредоставления
вышеуказанных документов, или если информация в них будет неполной, неразборчивой,
противоречивой.
3. Гарантия не включает в себя периодическое обслуживание, установку, настройку изделия на дому у
владельца, чистку аудио-видео головок.
4. Не подлежат гарантийному ремонту изделия с дефектами, возникшими вследствие:
- механических повреждений;
- несоблюдении условий эксплуатации или ошибочных действий владельца;
- неправильной установки, транспортировки;
- стихийных бедствий (молния, пожар, наводнение и т. п.), а также других причин, находящихся вне
контроля продавца и изготовителя;
- попадания внутрь изделия посторонних предметов, жидкостей, насекомых;
- ремонта или внесения конструктивных изменений неуполномоченными лицами;
- использования аппаратуры в профессиональных целях;
- отклонений от Государственных Технических Стандартов питающих, телекоммуникационных и
кабельных сетей;
- при выходе из строя деталей, обладающих ограниченным сроком службы.
5. Настоящая гарантия не ущемляет законных прав потребителя, предоставленных ему действующим
законодательством.
РУССКИЙ
3207.qxd 28.10.03 13:10 Page 8
