English Instruction for use CHEST FREEZERS
fiCONS91214
4
GB
To switch on: Turn the control (l) to the right
adjust temperature to the level you require, between:
- Min. (slight cooling) and
- max. (lowest temperature)
To switch off: Turn the control to the left
Temperature settings must be according to:
- ambient temperature of the appliance
- quantity of stored foodstuff
- frequency of opening
We recommend a medium setting.
You will soon learn which is the most suitable setting for
your requirements.
5 Indicator-lights (m,n,o)
If your appliance is equipped with indicator-lights, the
following guide explains what is meant by each light up:
- green = CONTROL
The appliance is under current
and operating
The green control light must always be on when the
appliance is connected to the mains and switched on. It is
very important to pay attention to this, because in the event
of a power failure, the red and yellow lights stop operating
and do no longer provide a warning.
- - red = ALARM
Interior temperature too high
If the red indicator-light goes on, there may be several
reasons for this, namely:
• First start-up of appliance
• Restart after defrosting
• Filling freezer with fresh food
In these cases it is normal that the red indicator-light goes
on. It goes off automatically when the interior temperature
reaches approximately –18°C.
Switch on the FAST FREEZE SWITCH (if equipped with)
(FIG.4). (switch off again not more than 24 hours later or
when the red light has gone off).
Reopen the appliance, if possible, only after the red light
has gone off.
If the red control light nevertheless stays on after 12 to 24
hours, there may be serious problems.
Consult the Troubleshooting guide “ what is when...”
chapter 18
- yellow = FAST FREEZE SWITCH is on and the
thermostat function is disabled.
The compressor continues cooling until the FAST FREEZE
switch is turned off again.
6 Warning Buzzer (Acoustic alarm)
If your appliance is supplied with a buzzer, it will sound
when the red indicator-light goes on. The buzzer is silenced
automatically when you turn on the FAST FREEZER
SWITCH.
7 Start-up
1. Fully unpack the appliance.
2. Remove the polystyrene parts in the compressor
chamber (if supplied).
3. Remove documents and any accessories from the
inside of the appliance.
4. Clean the interior with a mixture of lukewarm water
and vinegar, and dry thoroughly with a cloth.
5. Close the appliance.
6. Insert the plug in the socket
7. Switch on the appliance by turning the temperature
control (FIG.4) to the right (For the time being, turn the
controller fully to the right to Max position).
(green and red lights go on).
8. If equipped with a FAST FREEZE SWITCH, turn it on
(yellow light goes on too).
9. Do not open the appliance any more for about 4 hours
respectively as long as the red light is on, to allow the
temperature in the inner compartment to drop to the
necessary level.
10. You can now fill the appliance with any amount of
deep frozen food (purchased ready frozen goods).
(Consult the following chapter “Maximum stacking
height”).
11. Turn off the FAST FREEZE SWITCH again after 24
hours at the latest.
12. If you wish to freeze fresh, unfrozen food, go on to the
following chapter “Freezing/storage of fresh food”.
Important!
Do not store any bottles containing liquids. Liquid expands
when frozen and the bottle can explode. Never keep
containers with explosive substances (gas lighters, petrol,
ether and the like) in the freezer compartment of the
appliance.
When storing ready frozen food, you must observe the
manufacturer’s instructions on the food packaging.
Deep frozen ice-cream and ice lollies must be eaten only a
few minutes after being taken from the appliance to avoid
injury to lips and tongue (danger of skin detachment). For
the same reason, avoid touching
the inner walls with wet hands. We advise you to use
defrosted or slightly frozen products within short time. As a
rule, such products are not suitable for re-freezing.
8 Freezing / storage of fresh food
Almost all fresh products are suitable for freezing and
storage in the appliance.
For the most common of these products, we provide a table
with instructions on acceptable storage times and the most
suitable packing material (see “storage table” at the back of
this user manual).
Label the fresh products clearly as they are not easy to
identify when deep frozen in transparent freezer-bags.
We advise you to use commercially available labels for
frozen foods.
Pack fresh products in portions suitable for your household
to prevent defrosting of quantities that are too large for
consumption in one day in your household.
Label the portions with at least the following information:
• Product name (e.g. beef fillet)
• Weight of portion
• Quantity (total of pieces)
• Freezing date
