 How to change the door opening

This appliance has reversible doors but is delivered with a right hinged door. The left hand hinge kit

comes with the unit (in the box), should you wish to reverse the hinge on your unit.

ype A (for full glass/stainless steel door)

1. Lower hinge (Right) 2 . Screws 3 .Door axis

or 5.

op hinge (Right)

6. H

inge Screws

op hinge (Left) 8.

ole cover 9.

wer hinge (Left)

10. D

oor limit device

11. S

crew

1. Open the door to a 90 degrees angle, take out the 2 screws (2) from lower door axis (3), remove

the door (4), Remove the axis plate (3) from the door, (Fig. A).

. U

nscrew the screw (11) located underneath the doorframe and the limit device (10), and relocate

it at left end side of the door frame. (Fig. A/B)

3. Take out the 3 hinge screws (6) from the top hinge (right) (5) and remove it. (Fig. C)

emove decorative nail (8) from left top of cabinet and install spare top hinge (Left) (7) at left top

of cabinet with 3 screws. (Fig. D)

llowing the above procedure, install the spare lower hinge to the left (9). (Fig. E)

6. Install and aligned the door.

nsert the plastic caps to cover the holes(8)
