SiBE07-618_D Troubleshooting
Service Diagnosis 59
4. Troubleshooting
4.1 Error Codes and Description
★
: Displayed only when system-down occurs.
Error Codes Description
Reference
Page
System
00
Normal —
U0★
Refrigerant shortage 89
U2
Low-voltage detection or over-voltage detection 91
U4
Signal transmission error (between indoor unit and outdoor unit) 65
UA
Unspecified voltage (between indoor unit and outdoor unit) 66
Indoor
Unit
A1
Indoor unit PCB abnormality 60
A5
Freeze-up protection control or heating peak-cut control 61
A6
Fan motor (AC motor) or related abnormality 63
C4
Indoor heat exchanger thermistor or related abnormality 64
C9
Room temperature thermistor or related abnormality 64
Outdoor
Unit
E1
Outdoor unit PCB abnormality 67
E5★
OL activation (compressor overload) 68
E6★
Compressor lock 69
E7
DC fan lock 70
E8
Input overcurrent detection 71
EA
Four way valve abnormality 72
F3
Discharge pipe temperature control 74
F6
High pressure control in cooling 75
H0
Compressor system sensor abnormality 76
H6
Position sensor abnormality 77
H8
CT or related abnormality 79
H9
Outdoor temperature thermistor or related abnormality 81
J3
Discharge pipe thermistor or related abnormality 81
J6
Outdoor heat exchanger thermistor or related abnormality 81
L3
Electrical box temperature rise 83
L4
Radiation fin temperature rise 85
L5
Output overcurrent detection 87
P4
Radiation fin thermistor or related abnormality 81
U7
Signal transmission error (on outdoor unit PCB) 92
