Specifications Si04-703A
14 Specifications
60Hz 220V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Units FTKS50FVLT FTKS60FVLT FTKS71FVLT
Outdoor Units RKS50FVLT RKS60FVLT RKS71FVLT
Capacity
Rated (Min.~Max.)
kW 5.0 (1.7~6.0) 5.85 (1.7~6.7) 7.6 (2.3~8.3)
Btu/h 17,100 (5,800~20,500) 20,000 (5,800~22,900) 25,900 (7,800~28,300)
kcal/h 4,300 (1,460~5,160) 5,030 (1,460~5,760) 6,540 (1,980~7,140)
Running Current Rated A 7.2 9.6 13.8
Power Consumption
Rated (Min.~Max.)
W 1,550 (440~2,080) 2,080 (440~2,400) 3,010 (570~3,580)
Power Factor % 97.9 98.5 99.1
COP
Rated (Min.~Max.)
W/W 3.23 (3.86~2.88) 2.81 (3.86~2.79) 2.52 (4.04~2.32)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30 30
Max. Interunit Height Difference m 20 20 20
Chargeless m 10 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20 20
Indoor Unit FTKS50FVLT FTKS60FVLT FTKS71FVLT
Front Panel Color White White White
Airflow Rate
m³/min
(cfm)
H 14.7 (519) 16.2 (572) 17.4 (614)
M 12.4 (438) 13.6 (480) 14.6 (516)
L 10.3 (364) 11.4 (403) 11.6 (410)
SL 9.5 (335) 10.2 (360) 10.6 (374)
Fan
Type Cross Flow Fan Cross Flow Fan Cross Flow Fan
Motor Output W 43 43 43
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof Removable/Washable/Mildew Proof
Running Current (Rated) A 0.16 0.19 0.21
Power Consumption (Rated) W 34 40 45
Power Factor % 96.6 95.7 97.4
Temperature Control Microcomputer Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366 337×1,147×366
Weight kg 12 12 12
Gross Weight kg 17 17 17
Operation
Sound
H/M/L/SL dBA 43/39/34/31 45/41/36/33 46/42/37/34
Outdoor Unit RKS50FVLT RKS60FVLT RKS71FVLT
Casing Color Ivory White Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD 2YC63BXD
Motor Output W 1,100 1,100 1,920
Refrigerant Oil
Type FVC50K FVC50K FVC50K
Charge L 0.65 0.65 0.75
Refrigerant
Type R-410A R-410A R-410A
Charge kg 1.50 1.50 1.70
Airflow Rate m³/min (cfm)
HH 50.9 (1,797) 54.2 (1,914) 59.4 (2,097)
H 48.9 (1,727) 50.9 (1,797) 59.4 (2,097)
L 41.7 (1,472) 45.0 (1,589) 46.3 (1,635)
Fan
Type Propeller Propeller Propeller
Motor Output W 53 53 53
Running Current (Rated) A 7.04 9.41 13.59
Power Consumption (Rated) W 1,516 2,040 2,965
Power Factor (Rated) % 97.9 98.5 99.2
Starting Current A 7.2 9.6 13.8
Dimensions (H×W×D) mm 735×825×300 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 792×960×390 792×960×390 792×960×390
Weight kg 47 47 55
Gross Weight kg 52 52 61
Operation
Sound
H/SL dBA 47/44 49/46 53/49
Drawing No. 3D056228 3D056229 3D056230
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
