Vacuum cleaner
For appliances equipped with suitable acces-
sories.
- Release the levers (8 Fig. 3) and remove
the cover (9 Fig. 4) complete with the mo-
tor unit and floater-holder (46 Fig. 4).
- Remove the polyester filter (10 Fig. 5).
- Check, if applicable, that inside the de-
vice to be set the paper bag (11 Fig. 5).
- If the paper bag (11 Fig. 5) is not there,
install it, if necessary, acting as follows:
Install the paper bag (11 Fig. 6) in the
nozzle (12 Fig. 6) until it passes the band-
ing (13 Fig. 6).
-
Reassemble the polyester filter
(10 Fig.
5).
- Re-mount the floater-holder (46 Fig. 35),
with the “FRONT” arrow aligned with the
front part of the machine (58 Fig. 35);
also re-mount the cover (9 Fig. 35) and
block it via the levers (8 Fig.3).
- Insert, as far as possible, the sleeve (14
Fig. 7) of the suction hose into the nozzle
(15 Fig. 7) on the drum.
- To release the sleeve (14 Fig. 7) turn the
lever (16 Fig. 7) clockwise and then pull
the sleeve outwards (14 Fig. 7).
- Connect the ergonomic handle (17 Fig. 8)
or the hose (18 Fig. 8) depending on the
model, with the extension (19 Fig. 8).
- Connect the two rigid extensions (19-
20 Fig. 9) by aligning the two reference
points (21-22 Fig. 9).
- Attach to the rigid extension (20 Fig. 10)
the desired accessory ( the vacuum noz-
zle, the dust brush, the accessory for tight
spaces, the floor nozzle etc..
NOTES:
For models equipped with ergonomic handle
is possible to adjust the suction force, by act-
ing the selector (23 Fig. 11).
By opening the window (24 Fig. 11) you get a
lower suction force.
Connecting the electrical brush
For devices with socket:
- Connect the electrical brush’s plug to the
socket (25 Fig. 12) located on the top of
the vacuum (maximum output 200 W).
Tools connection
NOTE:
A relevant hose is supplied for these types of
machine, with suitable tool attachments.
Power tool connection
For appliances fitted with relative outlet.
- Lift the cover (47 Fig. 13) and connect
the power tool plug to the outlet (48 Fig.
13) present on the head of the vacuum
cleaner (maximum power allowed 2000
W).
Pneumatic tool connection
For appliances fitted with relative
attachments.
- Connect the hose (49 Fig. 13) of the
pneumatic tool to the relative fitting
(50 Fig. 13) present on the head of the
vacuum cleaner.
- Connect the pneumatic power supply
line (51 Fig. 13) to the fitting (52 Fig.
13) present on the head of the vacuum
cleaner (maximum pressure allowed 10
bar).
Liquid suction
For appliances equipped with suitable acces-
sories.
- Release the levers (8 Fig. 3) and remove
the cover (9 Fig. 4) complete with the mo-
tor unit and floater-holder (46 Fig. 4).
- Remove the polyester filter (10 Fig. 5) if
present.
- Remove the paper bag (11 Fig. 5) if pre-
sent.
- Re-mount the floater-holder (46 Fig. 35),
with the “FRONT” arrow aligned with the
front part of the machine (58 Fig. 35);
also re-mount the cover (9 Fig. 35) and
block it via the levers (8 Fig.3).
- Insert, as far as possible, the sleeve (14
Fig. 7) of the suction hose into the nozzle
