SiBE12-314 Heat Pump
Specifications 13
2. Heat Pump
2.1 Indoor Units
Wall Mounted Type
230V, 50Hz
Model
FTXS25BVMB FTXS35BVMB
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.4 (261) 7.5 (265) 7.4 (261) 7.5 (265)
M 5.8 (205) 6.3 (222) 5.9 (208) 6.3 (222)
L 4.1 (145) 5.0 (177) 4.4 (155) 5.2 (184)
SL 3.6 (127) 4.5 (159) 3.8 (134) 4.6 (162)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimension mm 834×325×258 834×325×258
Weight kg 8 8
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/33/28/25 39/33/26/23 39/34/29/26
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D040170A 3D040171A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model
ATXS25BVMB ATXS35BVMB
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.8 (275) 7.8 (275) 8.0 (282) 7.8 (275)
M 6.0 (212) 6.5 (229) 6.2 (219) 6.6 (233)
L 4.2 (148) 5.3 (187) 4.5 (159) 5.4 (191)
SL 3.5 (124) 4.6 (162) 3.8 (134) 4.7 (166)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removal-Washable-Mildew Proof Removal-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185
Packaged Dimension mm 834×325×258 834×325×258
Weight kg 8 8
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 38/32/25/22 38/33/28/25 39/33/26/23 39/34/29/26
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D040168A 3D040169A
