CORDLESS DRILL/DRIVER

OPERATION

Machine structure

The machine consists of a plastic case with a DC motor and a planetary gear located in it. The gearbox is equipped

with an adjustable mechanical clutch, providing a limitation of the maximum torque on the spindle. The body

goes into the handle in which the switch is installed. The lower part of the handle has a connector to attach the

battery.

LED working light is located above the switch in front. (pos.9, pic.1) For the model CDL-18-02 LED working light is

located at the bottom of the handle.

The machine is equipped with a hook 5 (pic. 1) for hanging by a belt or a pocket of working clothes. The hook is

xed with a screw to the body and can be installed both on the right and on the left side of the body.

The battery is equipped with a residual charge indicator 12 (рис. 1), which is enabled using the button 11 (pic. 1).

The indicator turns o automatically after 3…4 sec from the moment you press the button 11.

The machine and charger have keys preventing the installation of batteries of inadequate rated voltage and

design.

Before using the tool you must:

– after transportation in winter conditions before turning on, withstand at room temperature until complete

drying of water condensate;

– wipe the exterior of the machine with a cloth;

– check the voltage of the charger. The voltage of the power supply must correspond to the value indicated on

the charger label;

– x the workpiece;

– check the compliance of the rated voltage of the machine to the rated voltage of the battery. Using a battery

with a higher rated voltage will damage the machine;

– put on protective equipment (glasses, headphones, gloves) before starting work, put the tool in a comfortable

position and take a steady posture;

– try the machine idling (also after replacing drill or bit).

Install and remove battery

Before removing or installing battery as well as before transporting and storing the machine set the direction of

rotation switch 4 (pic 1) in the middle position to avoid accidental turning on the machine.

ATTENTION!

Never connect batteries other than the original design or type to the tool. The use of batteries

not intended for this model of tool can lead to failure of both the tool and the battery.

Installation

Attach a charged battery to the tool moving it until click along the guides in the lower part of the handle. Make

sure the battery is rmly xed and not staggering.

Do not use excessive force when installing the battery. If the battery is not installed on the tool without much

eort, it may be a sign of damage or inconsistencies with this type or model of the tool.

Removal

To remove the battery, press the release button 7 (pic. 1) and slide the battery forward along the guides until it is

completely separated from the tool case.
