CORDLESS DRILL/DRIVER

Battery charge

ATTENTION!

The charger should only be connected to a single phase AC power network, the voltage of

which corresponds to the voltage indicated on the label.

Plug the charger into wall outlet. In 1…2 s indicator 16 (pic. 1) of the charger glows green, which indicates

readiness for work.

Install the rechargeable battery into the charger guides until it stops, do not put much eort. If the battery is not

installed on the charger without much eort, check that the charger and battery match the rated voltage and

model. If the battery is low or not fully charged, charger indicator 16 (pic. 1) will change the color of the glow from

green to red, which indicates the ongoing process of charging. Battery indicator 12 (pic. 1) will ash, reecting the

charging process.

Upon reaching full battery charge the charger indicator 16 switches to green, the indicator on the battery will

glow without blinking.

ATTENTION!

Battery charging is possible at ambient temperatures from 0 °С to +40 °С. DO NOT charge the

battery when the ambient temperature is negative.

NOTE. Remember to turn o the charger when charging is complete.

Your tool is equipped with a lithium-ion rechargeable battery which does not have memory eect. Batteries of

this type are rechargeable.

Keep the battery charged at a temperature not lower than 0 °С.

NOTE. New battery can reach its rated capacity after two or three charge-discharge cycles.

Battery charge level can be estimated using the indicator 12 (pic. 1) located on the battery case. The indicator

turns on when you press the button 11 (pic. 1) and turns o automatically after 3..4 sec. The glow of the three

elements of the indicator indicates a full battery, if glows one then the charge is about 30% and it is time to charge

the battery.

Reversal of rotation

ATTENTION!

The reversal of rotation must be done only when the engine is o. It is forbidden to switch the

direction of rotation while the machine is running.

The direction of rotation of the spindle is changed by the switch 4 (pic. 1). The switch has 3 xed positions. When

you press the switch on the right until it stops– right-hand spindle rotation is activated, when press to the left

- left-hand. Corresponding symbols are printed on the movable switch bar. The middle position of the switch

corresponds to the lock of the engine switch, at the same time, when you press the switch the power does not

move to the motor, and only the work area illumination turns on.

Speed adjustment

The switch of the tool 8 (pic. 1) allows you to increase the speed of rotation from zero to maximum smoothly.

Rotational speed depends on the degree of pressure on the switch, the greater the degree of pressing on the

switch - the higher the speed of the chuck.

The machine is equipped with an electric spindle lock; it allows you to almost instantly stop the spindle when

you release the switch. Electric brake operation may be accompanied by a spark discharge visible through the

ventilation holes of the tool case. In this regard, the spark discharge in the tool engine, caused by abruptly

releasing the switch, is not a sign of any malfunction.
