• Indoor Units • Cooling Only/Heat Pump • FCQH-D8VEB
• Split Sky Air • Indoor Units
9
5 Dimensional drawing & centre of gravity
5 - 4 Dimensional Drawing
FCQH71-140D8
3D056851
Transmitting part
Remote control dimensions
Pipe connection side
Drain connection side
Receiver installation procedure
Receiver
Decoration panel
Remote controller holder installation
procedure (installation to wall surface)
Receiver detail
Wireless remote control kit for each decoration panel
Wireless remote control kit
Decoration panel
BRC7F532F BRC7F533F
BYCQ140CW1
Liquid crystal
remote control
(wireless)
Remote control holder
