Kenwood TK-3406M2 [10/21] Charging the battery pack
![Kenwood TK-3406M2 [10/21] Charging the battery pack](/views2/1781348/page10/bga.png)
4
CHARGING THE BATTERY PACK
The battery pack is not charged at the factory; charge it before
use.
ATTENTION: Always switch OFF a transceiver equipped with a
battery pack before inserting the transceiver into the charger.
1 Plug the AC adapter cable into the jack located on the rear
of the charger.
2 Plug the AC adapter into an AC outlet.
3 Match the Holder to the type of battery pack to be charged
so that when inserting the Holder, the battery type name
can be seen on the bottom of the charger. After inserting the
Holder into the charger, press the locking tabs to secure it in
place.
Holder
Li-ion battery
charger
Ni-MH battery
charger
• To remove the Holder, squeeze the locking tabs together then
pull the Holder out of the charger.
4 Slide a battery pack or a transceiver equipped with a battery
pack into the charging slot of the charger.
• Make sure the metal contacts of the battery pack mate securely
with the charger terminals.
• The indicator lights red and charging begins.
Indicator
