Kenwood TK-3406M2 [12/21] Installing the optional speaker microphone or headset

INSTALLING THE OPTIONAL SPEAKER/ MICROPHONE

(OR HEADSET)

Note: The transceiver is not fully water resistant when using a

speaker/ microphone or headset.

1 Insert the speaker/ microphone (or

headset ) plugs into the speaker/

microphone jacks of the transceiver.

2 Place the locking bracket over the

speaker/ microphone (or headset) plugs

so that the locking tabs insert into the

transceiver grooves.

• Push down on the locking bracket to

slide it into place.

3 While holding the locking bracket in

place, push it towards the bottom of the

transceiver until the tabs on the bracket

click into place.

• To remove the locking bracket, push

the bracket up from the base.
