1 04-19
IMPORTANT
BEFORE USE READ THESE INSTRUCTIONS AND RETAIN FOR FUTURE REFERENCE
INTRODUCTION
The following instructions contain important information about
the machine and safety advice for the operator. Equipment must
be operated, serviced and maintained in accordance with the
manufacturer’s instructions. If in doubt contact the supplier of
your machine.
Read all instructions before using the
machine
PRODUCT INFORMATION
The Hydromist range of carpet soil extraction machines are
designed for the efficient cleaning of carpets and upholstery. This
machine is for indoor use only. The machine is intended for
commercial use, for example in hotels, schools, hospitals,
factories, shops, offices, rental businesses and other than normal
housekeeping purposes.
TECHNICAL SPECIFICATIONS
Model
Hydromist 35
Product Code
HM35
Voltage AC (~)/ Frequency
V/Hz
230/50
Vacuum Motor Power
W
1350
Airflow rate
l/s
42.5
Solution Flow rate
l/min
6.8
Vacuum / Water lift
kPa /
mmwg
30 / 3059
Solution tank capacity
litres
35
Recovery tank capacity
litres
35
Pump type
Electrovanne
Pump power
W
180
Pump pressure
bar/psi
6.9 / 100
Brush width
cm
45
Brush speed
rpm
1800
Brush adjustment
Floating
Sound pressure level
dB(A)
78
Dimensions (L x W x H)
cm
93 x 47 x 88
Weight
kg
47
Cable length
m
15
Warranty
1 year subject to
conditions
Handle vibration does not exceed 2.5 m/s² when operating
on a smooth floor surface.
Noise levels measured at a distance of 1 metre from
machine and 1.6 metres above floor, when operating on a
hard floor. Measurements recorded using a hand held
meter.
Above dimensions are approx. Since the company’s policy
is to continuously improve the product, there could be
changes without prior notice.
WASTE ELECTRICAL & ELECTRONIC EQUIPMENT
(WEEE)
DO NOT dispose of this device with unsorted
waste. Improper disposal may be harmful to the
environment and human health. Please refer to
your local waste authority for information on
return and collection systems in your area.
IMPORTANT SAFETY ADVICE
The safety information described in this manual provides basic
precautions and supplements standards in force in the country
where the machine is used.
This symbol warns the operator of hazards and unsafe
practices which could result in severe personal injury
or death.
WARNING – to reduce the risk of injury,
electric shock or fire.
1. This machine must only be used for the manufacturer’s
approved application as described in this manual.
2. The machine must be unpacked and assembled in
accordance with these instructions before connecting to
the electrical supply.
3. Only genuine accessories and spare parts provided with the
machine or those approved by the manufacturer should be
used. The use of other accessories may impair the safety of
the machine. All repairs must be performed by a qualified
service agent.
4. DO NOT modify the machine from its original design.
5. Operators must be fully trained in the use of the machine in
accordance with these instructions, able to perform regular
user maintenance and the correct selection of accessories.
6. Operators should be physically capable to manoeuvre,
transport and operate the machine.
7. Operators should be able to recognise unusual operation of
the machine and report any problems.
8. This machine is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the machine by a person responsible for their safety.
EC Declaration of Conformity
Machine Type: Carpet soil extraction machines
Model: HM35…,
This machine is in conformity with the following EU
directives:
Machinery Directive 2006/42/EC
The EMC Directive 2014/30/EU
Applied harmonised standards:
EN60335-1, EN60335-2-68, EN55014-1, EN55014-2,
EN62233, EN61000-3-2, EN61000-3-3
Truvox International Limited
Unit C (East), Hamilton Business Park,
Manaton Way, Botley Road,
Hedge End, Southampton,
SO30 2JR, UK
Malcolm Eneas
Operations Manager
Southampton, 21/08/2018
