Pioneer XDV-P9-II [74/80] Installing the dvd player unit
![Pioneer XDV-P9-II [74/80] Installing the dvd player unit](/views2/1007831/page74/bg4a.png)
73
Installation
Installing the DVD Player Unit
7 Mounting Horizontally
7 Mounting Vertically
Bracket
Use the holes indicated
with arrows.
Tapping screw (6 × 16 mm)
Screw
(4 × 8 mm)
Mounting board
Drill 4 to 4.5 mm diameter holes.
Bracket
Use the holes indicated
with arrows.
Mounting board
Tapping screw (6 × 16 mm)
Screw
(4 × 8 mm)
Drill 4 to 4.5 mm diameter holes.
