Error Codes: System Malfunctions ESIE04-01
3–96 Part 3 – Troubleshooting
3
1
3
4
5
4.6 Centralized Address Setting Error (UC)
Remote Control
Display
UC
Applicable Models All indoor unit models
Method of
Malfunction
Detection
Indoor unit microcomputer detects and judges the centralized address signal according to the
transmission between indoor units.
Malfunction
Decision
Conditions
When the microcomputer judges that the centralized address signal is duplicated
Supposed Causes
■ Faulty centralized address setting
■ Faulty indoor unit PC board
Troubleshooting
Caution Be sure to turn off power switch before connect or disconnect connector, or parts damage may be
occurred.
Are devices
relating to centralized
control connected
to the indoor
unit?
Ye s
No
Change the setting so that the centralized
address is not duplicated.
Replace the indoor unit PC board.
(S2607)
