Radio operation

OPERATION

· Set Function switch to RADIO position thus the Power LED indicator should light up.

· Select your desired broadcasting band with Band switch.

· Rotate the Tuning control regulator to receive the desired broadcast.

· Adjust the level of sound with Volume control switch.

· To turn off the radio, set the Function switch to TAPE position.

ANTENNA

· For FM reception, adjust the telescopic antenna to obtain the best reception on the band selected.

· The AM signals are picked up through the built-in ferrite antenna. The set should be placed to a position

for the best reception.

CAUTION:

· Do not connect FM antenna to an external antenna.

FM AND FM STEREO RECEPTION

Set the FUNCTION switch to the FM STEREO position. This is the ideal setting to listen to FM Stations as it

will provide Stereo Sound. If the reception is weak, the FUNCTION Switch can be set to FM MONO. The

reception will be stronger but the quality of sound will not be that of FM STEREO.

Cassette recorder operation

CONTROLS

· STOP/EJECT button

During operation, depress to stop all deck operation. Press again to open the cassette door.

· FAST FORWARD button and REWIND button

Press to rapidly advance the tape in either forward or reverse direction.

· PLAY button

Press to start playback.

· PAUSE button

Press to stop tape operation temporarily. Press again to resume tape operation.

· RECORD button

Press to start recording. PLAY button will be activated automatically.
