Soundmax SM-2407 [4/15] Compact disc operations

Radio operations

 Slide the function switch to RADIO position.

 Set the band switch to desired radio band.

 Rotate TUNING regulator to tune to a radio station. The frequency will be shown in the dial scale window.

 Rotate VOLUME regulator to adjust the volume level.

 To turn off the radio set the mode switch to TAPE (OFF) position.

FM stereo reception

If you want to receive FM stereo signal, set the band switch to FM ST position. The FM stereo indicator will

light. If stereo signal is too week select FM mode, the signal will be received in mono mode, but the

background noise will be reduced.

Antenna

 For FM reception, adjust the telescopic antenna appropriately to obtain the best reception on the band selected.

 The AM signal is picked up through the built-in ferrite antenna. The set should be placed to a proper

position for the best reception.

Compact disc operations

 Set the function switch to CD/MP3/USB position.

 Press OPEN button to open the disc compartment door.

 Put a disc into the disc compartment with label side up and close the disc compartment door by pulling

it down gently.

Play/pause mode

 When you insert a disc, the total number of tracks contained will be displayed. Press PLAY/PAUSE

button to start playback. The number of current track will be displayed.

 Press PLAY/PAUSE button to pause at any track when playing. Press this button again to resume

playback.

 To stop the disc, press STOP button. This will reset the disc to the first track.

 To remove the disc from the unit open the disc compartment by pressing OPEN button.

 Always press STOP button before opening the disc compartment door.

Skip and search mode

 Press NEXT/UP button once to skip to the next track. Press and hold this button to search for a

particular point at high-speed forward. Release the button to resume normal play.
