List of Functions SiBE18-621
2 List of Functions
1. List of Functions
Category Functions
RMXS112·140·160E7V3B
Category Functions
RMXS112·140·160E7V3B
Basic
Function
Inverter (with Inverter Power Control)
{
Health &
Clean
Air Purifying Filter with Bacteriostatic &
Virustatic Functions
—
Operation Limit for Cooling (°CDB)
–5
~
46
Photocatalytic Deodorizing Filter —
Operation Limit for Heating (°CWB)
–15
~
15.5
Air Purifying Filter with Photocatalytic
Deodorizing Function
—
PAM Control —
Titanium Apatite Photocatalytic
Air-Purifying Filter
—
Compressor
Oval Scroll Compressor { Longlife Filter (Option) —
Swing Compressor — Mould Proof Air Filter —
Rotary Compressor — Wipe-clean Flat Panel —
Reluctance DC Motor { Washable Grille —
Comfortable
Airflow
Power-Airflow Flap — Filter Cleaning Indicator —
Power-Airflow Dual Flaps — Mold Proof Operation —
Power-Airflow Diffuser — Heating Dry Operation —
Wide-Angle Louvers — Good-Sleep Cooling Operation —
Vertical Auto-Swing (Up and Down) —
Timer
24-Hour On/Off Timer —
Horizontal Auto-Swing (Right and Left) — 72-Hour On/Off Timer —
3-D Airflow — Night Set Mode —
Comfort Airflow Mode —
Worry Free
“Reliability &
Durability”
Auto-Restart (after Power Failure) —
3-Step Airflow (H/P Only) — Self-Diagnosis (Digital, LED) Display
{
Comfort
Control
Auto Fan Speed — Wiring-Error Check —
Indoor Unit Silent Operation — Automatic Test Operation
{
Night Quiet Mode (Automatic)
{
Memory Function
{
Outdoor Unit Silent Operation
(Manual)
{
Anticorrosion Treatment of Outdoor
Heat Exchanger
{
Intelligent Eye —
Flexibility
Multi-Split / Split Type Compatible
Indoor Unit
—
Quick Warming Function
{
Flexible Voltage Correspondence —
Hot-Start Function — High Ceiling Application —
Automatic Defrosting { Chargeless —
Operation
Automatic Operation — Either Side Drain (Right or Left) —
Programme Dry Function — Power-Selection —
Fan Only —
Remote
Control
5-Rooms Centralized Controller
(Option)
—
Lifestyle
Convenience
New Powerful Operation
(Non-Inverter)
—
Remote Control Adaptor
(Normal Open-Pulse Contact) (Option)
—
Inverter Powerful Operation —
Remote Control Adaptor
(Normal Open Contact) (Option)
—
Priority-Room Setting —
Dlll-NET Compatible (Adaptor)
(Option)
—
Cooling / Heating Mode Lock —
Remote
Controller
Wireless —
Home Leave Operation — Wired —
ECONO Mode —
Indoor Unit On/Off Switch —
Signal Reception Indicator —
Temperature Display —
Another Room Operation —
Note:
{
: Holding Functions
— : No Functions
