4 Operation
User reference guide
16
RHBH/X04~16CB
ROTEX HPSU low temperature Bi‑bloc
4P384968-1B – 2017.04
4.6.4 Reading out information
To read out information
Prerequisite: You switched the permission level to Advanced end
user.
1 Go to [6]: > Information.
Possible read-out information
In menu… You can read out…
[6.1] Sensor information Room, tank or DHW, outside,
and leaving water temperature.
(If applicable)
[6.2] Energy metering Produced energy, consumed
electricity, and consumed gas.
[6.3] Error handling Error history and contact/
helpdesk number.
[6.4] User permission level Current user permission level.
[6.5] Actuators Status/mode of each actuator.
Example: Domestic hot water
pump ON/OFF.
[6.6] Operation modes Current operation mode.
Example: Defrost/oil return
mode.
[6.7] Running hours Running hours of the system.
[6.8] Version Version information about the
system.
4.6.5 Configuring date, time, units of
measurement, contrast and backlight
To configure time and date
Prerequisite: You switched the permission level to Advanced end
user.
1 Go to [1]: > Set time/date.
INFORMATION
Switch to Adv. end user to change daylight saving time and
12/24h notation.
To configure units of measurement
Prerequisite: You switched the permission level to Advanced end
user.
1 Go to [7.6]: > User settings > Unit of measurement.
Possible units of measurement settings
Setting Possible units of measurement
Decimal point ▪ Dot
▪ Comma
Temperature ▪ °C
▪ °F
Produced energy ▪ kWh
▪ MBtu
Flow ▪ l/min
▪ GPM
To configure the contrast of the user interface
Prerequisite: You switched the permission level to Advanced end
user.
1 Go to [7.1.1]: > User settings > Display > Contrast.
To configure the backlit LCD time of the user interface
Prerequisite: You switched the permission level to Advanced end
user.
1 Go to [7.1.2]: > User settings > Display > Backlit LCD time.
4.6.6 Configuring user profile and home pages
To set a user profile
Prerequisite: You switched the permission level to Advanced end
user.
1 Go to [7.1.3]: > User settings > Display > User profile.
2 Select a user profile and press .
Possible user profiles
If user profile = Detailed, you can see and do more on the home
pages.
User profile = Basic User profile = Detailed
15:20
20.0°C
Mon
Room
Actual temperature
15:20
20.0°C
17:30
Actual temperature
Room
Scheduled
Mon
Tue
To configure which home pages are made available to the
enduser
Prerequisite: You switched the permission level to Advanced end
user.
1 Go to [7.1.4]: > User settings > Display > Available home
pages.
Result: The home pages that are possible for your system
layout are listed.
2 Select a home page and press .
3 Do one of the following:
▪ To display the home page, select Yes and press .
▪ To hide the home page, select No and press .
4.6.7 Locking and unlocking buttons and
functions
About locking and unlocking
You can use the following locking modes:
▪ Button lock: Locks all buttons to prevent children from changing
settings.
▪ Function lock: Locks a specific function to prevent people from
changing its settings.
Possible function locks
Lock If active, people cannot…
Room On/OFF Turn ON or OFF the room
temperature control.
LWT On/OFF Turn ON or OFF the leaving
water temperature (main +
additional) control.
Tank On/OFF Turn ON or OFF the domestic
hot water control.
Temperature up/down Adjust temperatures.
Quiet mode Use quiet mode.
Holiday Use holiday mode.
Operation mode Set the space operation mode.
User settings Change settings in [7]: > User
settings.
To check if locking is active
1 Press to go to one of the home pages.
2 If is displayed, button lock is active.
Note: If you are on a home page and try to use a function that is
locked, is displayed for 1second.
