14
TECHNICAL DATA
• HEATING SECTION WITH GAS DIRECT HEAT EXCHANGER
TYPE M.U.
1 2 3 4 5
Operating speed MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN
Heat exchanger Mod. MJ 30 MJ 30 MJ 40 MJ 20
(SUP)
M J20
(SUP)
M J30
(SUP)
MJ 30
(SUP)
MJ 30
(INF)
- MJ 40
(INF)
-
Burner tube Mod. MJ 30 MJ 40 MJ 40 MJ 20 + MJ 30 MJ 30 + MJ 40
Destination country IT IT IT IT IT
Category II
2H3+
II
2H3+
II
2H3+
II
2H3+
II
2H3+
kW
22.2 17.5 28.4 21.8 35.9 27.0 43.3 21,9 56.8 27,5
Heat input (burned)
kcal/h
19120 15050 24420 18690 30830 23180 37230 18834 48850 23650
Efficiency % 94 92 94 92 94 92 94 94 94 94
kW
20.9 16.1 26.7 20.0 33.7 24.8 40.7 20,6 53.4 25,9
Heat output (available)
kcal/h
17970 13840 22960 17200 28980 21320 35000 17716 45920 22274
Air flow-rate
m3/h
3825 5100 6375 7650 10200
Max working static pressure
Pa
200 200 200 200 200
Inlet/outlet ∆t
°K
16.2 12.5 15.5 11.6 15.7 11.5 15.8 8.0 15.5 7.5
External air flow-rate
m3/h
1020 1275 1530 1870 2125
Min gross fume temperature °C
≈120 ≈110 ≈130 ≈115 ≈120 ≈110 ≈ 110 ≈ 110 ≈ 110 ≈ 110
TR safety thermostat
Quantity N° 1 1 1 2 2
Reset Type Automatic Automatic Automatic Automatic Automatic
Calibration °C 60 60 60 60 60
LM safety thermostat
Quantity N° 1 1 1 2 2
Reset Type Manual Manual Manual Manual Manual
Calibration °C 100 100 100 100 100
Differential pressure switch mBar 0.65 1.03 2.08 0.65 (HIGH) 1.50-1.63 (SUP)
1.50-1.63 (LOW) 2.70 (LOW)
Fume extractor
Residual head Pa
≈60 ≈55 ≈50 ≈48 ≈55 ≈50 ≈55 ≈50
Electrical resistance 50W -
180Ω
-
180Ω
-
180Ω
- -
Diaphragm for max L
∅ int
42 47 52 44.0 (HIGH) 46.5 (HIGH)
46.5 (LOW) 50.0 (LOW)
Gas certification N° 0694BO0054 0694BO0054 0694BO0054 0694BO0054 0694BO0054
• FUEL GAS SETTING TABLE
The appliance is preset and tested in factory with methane G20.
TYPE M.U. 1 2 3 4 5
Methane G20
MAX MIN MAX MIN MAX MIN MAX (*) MIN (*) MAX (*) MIN (*)
Supply pressure mbar 20 20 20 20 20
Exchanger Mod MJ 30 MJ 30 MJ 40 MJ 20
(HIGH)
MJ 30
(LOW)
MJ 30
(HIGH)
MJ 40
(LOW)
Injector pressure mbar 12.0 7.5 13.5 8.0 13.0 7.0 12.5 13.5 13.5 13.0
N° of injectors N° 1 1 1 1 1 1 1
Injector ∅
mm 3.85 4.25 4.90 3.85 4.25 4.25 4.90
Consumption (1) m3/h 2.35 1.85 3.01 2.31 3.80 2.86 4.58 2.32 6.01 2.91
(1) G20 references:
Atmospheric pressure 1013 mBar
Gas temperature 15°C
Lower heating value 34.02 MJ/m3
TYPE M.U. 1 2 3 4 5
Methane G25 (2)
MAX MIN MAX MIN MAX MIN MAX (*) MIN (*) MAX (*) MIN (*)
Supply pressure mbar 25 25 25 25 25
Exchanger Mod
MJ 30
MJ 30 MJ40 MJ 20
(HIGH)
MJ 30
(LOW)
MJ 30
(HIGH)
MJ 40
(LOW)
Injector pressure mbar 12.0 7.5 13.5 8.0 13.0 7.0 12.5 13.5 13.5 13.0
N° of injectors N° 1 1 1 1 1 1 1
Injector ∅
mm 4.25 4.65 5.45 4.25 4.65 4.65 5.45
Consumption (3) m3/h 2.73 2.15 3.50 2.68 4.42 3.32 5.33 2.70 6.99 3.39
(*) In maximum speed operation both exchangers are active (higher + lower)
In minimum speed operation only one exchanger is active (higher)
(2) Only valid for the countries where it is distributed
(3) G25 references:
Atmospheric pressure 1013 mBar
Gas temperature 15°C
Lower heating value 29.25 MJ/m3
