15
TYPE M.U. 1 2 3 4 5
Propane G31 MAX MIN MAX MIN MAX MIN MAX (*) MIN (*) MAX (*) MIN (*)
Supply pressure mbar 37 37 37 37 37
Exchanger Mod MJ 30 MJ 30 MJ40 MJ 20
(SUP)
MJ 30
(INF)
MJ 30
(SUP)
MJ 40
(INF)
Injector pressure mbar 36.1 20.5 36.1 21.0 36.1 18.0 36.4 36.4 36.4 36.4
N° of injectors N° 1 1 1 1 1 1 1
Injector ∅
mm 2.30 2.55 3.00 2.30 2.55 2.55 3.00
Primary air diaphragm inner ∅
mm 28 28 35 28 28 28 35
Consumption (4) m3/h 0.91 0.72 1.16 0.89 1.47 1.10 1.77 0.90 2.32 1.13
kg/h 1.72 1.36 2.21 1.69 2.79 2.10 3.36 1.70 4.41 2.14
l/h 3.39 2.67 4.33 3.33 5.48 4.12 6.61 3.34 8.67 4.20
(4) G31 references:
Atmospheric pressure 1013 mBar
Gas temperature 15°C
Lower heating value 88 MJ/m3 - 11070 kcal/kg – 5635 kcal/
TYPE M.U. 1 2 3 4 5
Butane G30 MAX MIN MAX MIN MAX MIN MAX(*) MIN (*) MAX (*) MIN (*)
Supply pressure mbar 30 30 30 30 30
Exchanger Mod MJ 30 MJ 30 MJ40 MJ20 MJ30 MJ30 MJ40
Injector pressure mbar 29.0 19.0 29.0 19.0 29.0 19.0 29.0 29.0 29.0 29.0
N° of injectors N° 1 1 1 1 1 1 1
Injector ∅
mm 2.30 2.55 3.00 2.30 2.55 2.55 3.00
Primary air diaphragm inner ∅
mm 28 28 35 28 28 28 35
Consumption (5) \\m3/h 0.69 0.54 0.88 0.68 1.11 0.84 1.34 0.68 1.76 0.85
kg/h 1.75 1.38 2.24 1.72 2.83 2.13 3.41 1.73 4.48 2.17
l/h 3.04 2.39 3.89 2.98 4.91 3.69 5.92 3.00 7.77 3.76
(*) In maximum speed operation both exchangers are active (higher + lower)
In minimum speed operation only one exchanger is active (higher)
(5) G30 references:
Atmospheric pressure 1013 mBar
Gas temperature 15°C
Lower heating value 116.09 MJ/m3 - 10905 kcal/kg – 6285 kcal/
• COOLING SECTION AND HEAT PUMP:
TYPE M.U. 1 2 3 4 5
MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN
Total cooling capacity (1) kW 19.4 10.6 25.7 15.8 32.1 18.8 42.7 23.9 51.5 29.0
Compressor power input (1) kW 6.5 3.2 9.6 4.7 11.1 5.5 14.3 7.2 17.1 8.5
Heat input (2) kW 20.5 9.8 26.9 14.5 33.6 17.5 44.0 21.9 53.5 26.8
Compressor power input (2) kW 5.0 2.5 7.3 3.6 8.5 4.2 11.0 5.5 13.2 6.6
Qty. of refrigerant gas R407C kg 2 x 4.8 2 x 5.1 2 x 5.3 2 x 5.8 2 x 6.1
(1) Treated air 27°C / 50% R.H. External air 35°C
(2) Treated air 20°C. External air 7 °C / 90% R.H.
• ELECTRICAL DATA
TYPE M.U. 1 2 3 4 5
Three-phase power supply voltage
400V∼50Hz 3N
Power consumption for cooling kW 9.5 11.9 15.3 18.1 22.6
Current consumption for cooling A 17.6 22.2 30.4 35.6 45.3
Starting current A 35 52 73 98 130
Electrical protection degree IP 44
(1) Treated air 27°C / 50% R.H. External air 40°C
• LIMITS OF USE
External air (heating mode with gas heat exchanger) °C -15/+6
External air (heating mode with heat pump) °C +5/+30
External air (cooling mode) °C +15/+40
Internal air (heating and cooling modes) °C +5/+35
