PECULIARITY
- Winter functioning down to -15°C.
- Employing R410A eco-friendly refrigerating gas.
- Coefficient of performance - C.O.P. 4,6.
- Low frequency of defrost cycles.
- Automatic control of axial fans speed.
- Smooth-finned battery and hydrophilic treatment.
- Outer temperature sensor for specific heat pump functions.
- Auxiliary hydraulic connections.
- Water-flow switch to check appropriate water-flow rate.
- Advanced electronics.
- Machine equipped with horizontal storage unit, circulator, expansion tank water-flow
switch, pressure gauge, air vent.
C.O.P. ~ 4,6
BESST
REVERSIBLE HigH-performance HEAT PUMPS WITH
R410A ECO-FRIENDLY REFRIGERATING GAS
SERIES
