6 Technical data
Installation manual
11
RRLQ011~016CA
Outdoor unit for air to water heat pump
4P385895-1A – 2016.03
Q1DI Earth leakage circuit breaker (field
supply)
R1~R4 Resistor
R1T Thermistor (air)
R2T Thermistor (discharge)
R3T Thermistor (suction)
R4T Thermistor (heat exchanger)
R5T Thermistor (heat exchanger middle)
R6T Thermistor (liquid)
R7T
(RRLQ_W1)
Thermistor (fin)
R10T
(RRLQ_V3)
Thermistor (fin)
RC
(RRLQ_V3)
Signal receiver circuit
S1NPH Pressure sensor
S1PH High pressure switch
TC
(RRLQ_V3)
Signal transmission circuit
V1R
(RRLQ_V3)
Power module
V1R, V2R
(RRLQ_W1)
Power module
V2R, V3R
(RRLQ_V3)
Diode module
V3R
(RRLQ_W1)
Diode module
V1T
(RRLQ_V3)
Insulated gate bipolar transistor (IGBT)
X1M Terminal strip (power supply)
X6A Connector (option)
X77A
(RRLQ_W1)
Connector (option)
Y1E Expansion valve (main)
Y3E Expansion valve (injection)
Y1S Solenoid valve (4‑way valve)
Y3S Solenoid valve (hot gas pass)
Z1C~Z9C Noise filter
Z1F~Z4F Noise filter
