PECULIARITY
- Autonomous single-package equipment with automatic control of all functions by means
of a cutting-edge pCO microprocessor.
- Free-cooling, free-heating, filtering, heat recovery, room air expulsion and outdoor air
renewal by on-board mounted modulating ventilation unit.
- Maximum performance rate about 102%.
- Very high average seasonal efficiency.
- Possible partialization of both air replacement and of the cooling/heating capacity output.
- Absence of intermediate fluids.
- Operating temperatures between -20° and +40°C.
- Heating by heat pump up to +5°C; heating by condensing modulating gas burner down
to -20°C.
- Direct expansion refrigeration up to +40°C.
- Incorporated heat recuperator.
KLIMAXs
SERIES
condensing AUTONOMUS SINGLE-PACKAGE AIR
TREATMENT UNIT FEATURING TOP GLOBAL EFFICIENCY SYSTEMS
EFFICIENCY ~102%
