8
HYDRAULIC DATA
The following diagram shows the residual lifts with nominal water flow-rate ± 20%.
Do not work outside these curves
WATER FLOW RATE – LIFT DIAGRAM
WATER FLOW RATE m
3
/h
AVAILABLE LIFT kPa
Type 1-9
Type 2-10
Type 3-11
Type 5-13
T
yp
e 4-12
Type 6-14
Type 7-15
Type 8-16
