16
FA ROTEX RoCon mb • 09/2017
3 x Operation
Tab. 3-9 Factory setting of the permanent switching time programs
Temporary time programs
4 temporary time programs are available for special situations,
which make the permanent time programs or the currently set
operating mode ineffective for the duration of their validity.
The symbol of the temporary time program is displayed in the
header of the standard display for as long as the time program is
active.
1. [Party]: Immediate one-off extension of room heating.
a) If an automatic program is activated, the last valid
switching cycle is always extended. In the time prior to
switching cycle 1, control is carried out according to the
target room temperature set in the parameter [T-Room 1
Setpoint].
b) In all other operating modes, control is carried out accord-
ing to the target room temperature set in the parameter [T-
Room 1 Setpoint].
– The hot water generation is not affected.
– The time program runs for the set time period from activa-
tion.
2. [Away]: Immediate one-time setback up to 6 hours.
– In reducing mode, control is carried out according to the
target room temperature set in the "Set Temp Night"
rotary switch position in the parameter [T-Absence].
– The hot water generation is not affected.
– The time program runs for the set time period from activa-
tion.
3. [Holiday]: One-time calendar-controlled presence.
– Control is carried out only according to the settings for
"Sunday" in the [HC Program 1].
– The hot water generation is only controlled according to
the settings for "Sunday" in the [DHW Program 1].
4. [Vacation]: One-time calendar-controlled setback.
– In reducing mode, control is carried out exclusively
according to the target room temperature set in the "Set
Temp Night"
rotary switch position in the parameter
[T-Absence].
– Hot water generation according to the set target tempera-
tures and switching cycles in the [DHW Program 1] hot
water time program (see chap.
3.4.5).
– The calendar-controlled [Vacation] program is not
started if the "Standby" or "Manual Operation" operating
mode is active on the set start date.
Switching cycle 1 Switching cycle 2 Switching cycle 3
Time period On Off On Off On Off
Room heating / room cooling
Temperature setting
[T-Room 1 Setpoint]: 20 °C [T-Room 2 Setpoint]: 20 °C [T-Room 3 Setpoint]: 20 °C
[T-Reduced]: 10 °C
"HC Program 1"
Monday - Friday 06:00 22:00 - - : - - - - : - - - - : - - - - : - -
Saturday, Sunday 07:00 23:00 - - : - - - - : - - - - : - - - - : - -
"HC Program 2"
Monday - Friday 06:00 08:00 - - : - - - - : - - - - : - - - - : - -
Saturday, Sunday 07:00 23:00 - - : - - - - : - - - - : - - - - : - -
Domestic hot water generation
Temperature setting [T-DHW Setpoint 1]: 48 °C [T-DHW Setpoint 2]: 48 °C [T-DHW Setpoint 3]: 48 °C
"DHW Program 1"
Monday - Sunday 00:00 24:00 - - : - - - - : - - - - : - - - - : - -
"DHW Program 2"
Monday - Friday 05:00 21:00 - - : - - - - : - - - - : - - - - : - -
Saturday, Sunday 06:00 22:00 - - : - - - - : - - - - : - - - - : - -
"Circulation Time"
Monday - Friday 05:00 21:00 - - : - - - - : - - - - : - - - - : - -
Saturday, Sunday 06:00 22:00 - - : - - - - : - - - - : - - - - : - -
The following temporary time programs can be can-
celled at any time due to the manual changing of the
operating mode.
