![Daikin EKCBX008BCV3 [19/24] Field settings table](/views2/1789211/page19/bg13.png)
EKCBX/H008BCV3
Unit for air to water heat pump system
4P348534-1 – 2013.04
Operation manual
18
Field settings table
First
code
Second
code
Setting name
Installer setting at variance with default value
Default
value
Range Step UnitDate Value Date Value
0 User permission level
00 User permission level 3 2/3 1 —
1 Weather dependent set point
00 Low ambient temperature (Lo_A) –10 –20~5 1 °C
01 High ambient temperature (Hi_A) 15 10~20 1 °C
02 Set point at low ambient temperature (Lo_Ti) 40 25~55 1 °C
03 Set point at high ambient temperature (Hi_Ti) 25 25~55 1 °C
05 Weather dependent for cooling function
enable/disable
0 (OFF) 0/1 — —
06 Low ambient temperature (Lo2_A) 20 10~25 1 °C
07 High ambient temperature (Hi2_A) 35 25~43 1 °C
08 Set point at low ambient temperature (Lo2_Ti) 22 5~22 1 °C
09 Set point at high ambient temperature (Hi2_Ti) 18 5~22 1 °C
2 Disinfection function
00 Operation interval Fri Mon~Sun, All — —
01 Status 1 (ON) 0/1 — —
02 Start time 23:00 0:00~23:00 1:00 hour
03 Set point 70 55~80 5 °C
04 Interval 10 5~60 5 min
3 Auto restart
00 Status 0 (ON) 0/1 — —
4 Space heating off temperature
00 Installation related setting
01 Installation related setting
02 Space heating off temperature 25 14~25 1 °C
03 Installation related setting
04 Not applicable. Do not change the default value. — — — —
05 Not applicable. Do not change the default value. — — — —
06 Installation related setting
07 Installation related setting
5 Installation related setting
00 Installation related setting
01 Installation related setting
02 Installation related setting
03 Installation related setting
04 Installation related setting
6 Installation related setting
00 Installation related setting
01 Installation related setting
02 Not applicable. Do not change the default value.
————
Scheduled storage and reheat domestic water heating
03 Scheduled time storage
1 (ON) 0/1 1 —
04 Scheduled time storage start time
1:00 0:00~23:00 1:00 hour
05 Scheduled time reheat or continuous reheat
0 (OFF) 0/1/2 1 —
06 Scheduled time reheat start time
15:00 0:00~23:00 1:00 hour
07 Domestic hot water reheat set point
45 30~50 1 °C
08 Domestic hot water reheat set point hysteresis
10 2~20 1 °C
7 Installation related setting
00 Installation related setting
01 Installation related setting
02 Installation related setting
03 Installation related setting
04 Installation related setting
