17
HyperControl for Reason
|
User Guide
Reason Device Mappings
Mixer Devices
Mixer 14:2
Mixer 14:2 is a stereo mixer with 14 channels.
Since Axiom Pro can only control eight of those
channels at one time, you must use F-Keys F6
and F7 (F1+F2 and F1+F3 for Axiom Pro 25
users) to select between channels 1-8 and 9-14
respectively.
The tables below describe the functionality of the
Axiom Pro controls:
Axiom Pro 49/61 Encoder Knobs:
Soft-Key 1 2 3 4
Page 1 Pan EQ Enable Aux 1 -
Page 2 - Bass Aux 2 -
Page 3 - Treble Aux 3 -
Page 4 - - Aux 4 -
Page 5
- -
Aux Returns
-
Slider Mixer 14:2
(Chan. 1-8 selected)
Mixer 14:2
(Chan. 9-14 selected)
S1 Channel 1 level Channel 9 level
S2 Channel 2 level Channel 10 level
S3 Channel 3 level Channel 11 level
S4 Channel 4 level Channel 12 level
S5 Channel 5 level Channel 13 level
S6 Channel 6 level Channel 14 level
S7 Channel 7 level -
S8 Channel 8 level -
S9 Master level Master level
Axiom Pro 25 Encoder Knobs:
Soft-Key 1 2 3 4
Page 1 Level Pan EQ Enable Aux 1
Page 2 - - Bass Aux 2
Page 3 - - Treble Aux 3
Page 4 - - - Aux 4
Page 5
- - -
Aux Returns
