8
HyperControl for Reason
|
User Guide
Axiom Pro Hardware Controls
9
8
10 11 2 536
1 4 7
1. Slider Buttons
5
– The functionality of the slider buttons varies depending on the selected Device (i.e., the device that is
selected in the Sequencer):
• Mixer Devices:
By default, these buttons mute/un-mute mixer tracks. However, pressing the Flip button
4
will toggle the functionality
of the slider buttons and allows you to solo/un-solo mixer tracks.
• Instrument Devices:
The functionality of the slider buttons varies depending on what instrument Device is currently selected. The
“Instrument Devices” section of this User Guide covers individual devices in greater detail.
• Effects Devices:
The slider buttons are unused on effects Devices.
2. Sliders
5
– The functionality of the sliders varies depending on the selected Device:
• Mixer Devices:
The sliders control channel volume. Note that the 14:2 Mixer has 14 channels whereas Axiom Pro only has eight
sliders (not including the Master slider which is described below). When using the 14:2 mixer, use F-Keys F6 and F7
(F1+F2 and F1+F3 for Axiom Pro 25 users) to access mixer channels 1-8 and 9-14, respectively.
• Instrument Devices:
When controlling instrument Devices, the sliders cover some of the most commonly used controls for each Reason
instrument. The “Instrument Devices” section of this User Guide contains for more information about how the sliders
work with each specific instrument Device.
✓ NOTE: As soon as one of the Soft-Keys
6
is pressed to select a Control Page, the
sliders will no longer be mapped to their default on-screen controls. To map the sliders,
press the Flip button
4
, in which case the sliders will take on the mappings currently
assigned to the encoders.
• Effects Devices:
For most effects Devices, the sliders are unmapped. Press the Flip button
4
, if you prefer to use the sliders instead of
the encoder knobs to edit Effects device parameters
About Flipped Faders mode: HyperControl features a “Flipped Faders” mode that allows you to use the sliders to
control the parameters of a device instead of the encoder knobs. Please see the Flip Button description below to learn
how to use this feature.
5
Only available on Axiom Pro 49/61.
