SERVICE DATA AND SPECIFICATIONS (SDS)
ATC-151
C
D
E
F
G
H
I
K
L
M
A
B
ATC
SERVICE DATA AND SPECIFICATIONS (SDS) PFP:00030
COMPRESSOR
BJS000IH
LUBRICANT
BJS000J9
REFRIGERANT
BJS000JA
ENGINE IDLING SPEED
BJS000IK
Refer to EC-449, "SERVICE DATA AND SPECIFICATIONS (SDS)" . CR (with EURO−OBD).
Refer to EC-801, "
SERVICE DATA AND SPECIFICATIONS (SDS)" . CR (without EURO−OBD).
Refer to EC-1237, "
SERVICE DATA AND SPECIFICATIONS (SDS)" . HR (with EURO−OBD).
Refer to EC-1597, "
SERVICE DATA AND SPECIFICATIONS (SDS)" . HR (without EURO−OBD).
Refer to EC-1870, "
SERVICE DATA AND SPECIFICATIONS (SDS)" .K9K.
BELT TENSION
BJS000IL
Refer to EM-14, "Tension Adjustment" . (CR engine models).
Refer to EM-114, "
Tension Adjustment" . (HR engine models).
Refer to EM-242, "
Tension Adjustment" . (K9K engine models).
Model
CR engine models HR engine models K9K engine models
ZEXEL VALEO CLIMATE
CONTROL make KC59G
CR-10 SANDEN make SD6V12
Type Vane rotary Variable volume piston
Displace-
ment
cm
3
(cu
in)/rev
Max.
80 (4.88)
Theoretical displacement
96 (5.86)
Theoretical displacement
125.1 (7.63)
6.2 (0.38)
Min.
Cylinder bore × stroke mm (in) 5 vanes, φ51.0 × 7.28 5 vanes, φ50.2 × 8.5 —
Direction of rotation Clockwise (viewed from drive end)
Drive belt Poly V (4grooves) V-Ribbed (7 grooves) Poly V (6 grooves)
Model
CR engine models HR engine models K9K engine models
ZEXEL VALEO CLIMATE CON-
TROL make KC59G
CR-10 SANDEN make SD6V12
Name Nissan A/C System Oil Type R Nissan A/C System Oil Type S
Part number KLH00-PAGR0 KLH00-PAGS0
Capacity
m(lmpfl
oz)
Total in system — — 135 (4.75)
Compressor
(Service part)
charging
amount
— — 135 (4.75)
Model
CR engine models HR engine models K9K engine models
ZEXEL VALEO CLIMATE CON-
TROL make KC59G
CR-10 SANDEN make SD6V12
Type HFC-134a (R-134a)
Capacity
kg (lb)
0.475 ± 0.025 (1.04 ± 0.055) 0.475 ± 0.025 (1.04 ± 0.055) 0.55 ± 0.05 (1.21 ± 0.11)
