LU-6

[CR]

ENGINE OIL

PFP:KLA92

Inspection

BBS002R9

OIL LEVEL AND CONTAMINATION

● Before starting the engine, put vehicle horizontally and check the oil level. If the engine is already started,

stop it and allow 10 minutes before checking.

● Check that the oil level is within the range shown in the figure.

● If oil level is outside the range, adjust level.

● Check the oil for white turbidity or remarkable contamination.

● If the oil becomes turbid and white, it is highly probable that it is

contaminated with coolant. Find the cause and repair.

● When oil level gauge is inserted in guide, apply engine oil to rub-

ber seal of grip.

OIL LEAK

Check the following parts for engine oil leaks.

● Oil pan

● Oil pan drain plug

● Oil pressure switch

● Oil filter

● Front cover

● Cylinder head front cover

● Mating surfaces of cylinder block and cylinder head

● Mating surfaces of cylinder head and rocker cover

● Crankshaft oil seals (front and rear)

OIL PRESSURE CHECK

WARNING:

● Be careful not to burn yourself, as the engine oil is hot.

● Oil pressure check should be done in Neutral position.

1. Check the engine oil level. Refer to LU-6, "

OIL LEVEL AND CONTAMINATION"

2. Remove oil filter. Refer to LU-9, "OIL FILTER" .

3. Remove oil pressure switch using a deep socket (commercial

service tool).

PBIC1466E

PBIC1467E
