Nissan Note LAN SYSTEM онлайн
LAN-1
LAN SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION LAN
A
B
LAN
LAN SYSTEM
CAN
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS)“AIRBAG”and“SEATBELTPRE-TEN-
SIONER” .................................................................. 3
Maintenance Information .......................................... 3
RHD MODELS ...................................................... 3
LHD MODELS ....................................................... 3
Precautions When Using CONSULT-II ..................... 3
CHECK POINTS FOR USING CONSULT-II ......... 3
Precautions for Trouble Diagnosis ........................... 4
CAN SYSTEM ....................................................... 4
Precautions for Harness Repair ............................... 4
CAN SYSTEM ....................................................... 4
TROUBLE DIAGNOSES WORK FLOW .................... 5
When Displaying CAN Communication System
Errors ....................................................................... 5
WHEN A MALFUNCTION IS DETECTED BY
CAN COMMUNICATION SYSTEM ....................... 5
WHEN A MALFUNCTION IS DETECTED
EXCEPT CAN COMMUNICATION SYSTEM ........ 5
TROUBLE DIAGNOSIS FLOW CHART ............... 6
Diagnosis Procedure ................................................ 7
SELECTING CAN SYSTEM TYPE (HOW TO
USE SPECIFICATION TABLE) ............................. 7
ACQUISITION OF DATA BY CONSULT-II ............ 8
HOW TO USE CHECK SHEET TABLE ................ 9
CAN Diagnostic Support Monitor ........................... 15
DESCRIPTION OF “CAN DIAG SUPPORT
MNTR” SCREEN FOR ECM ............................... 15
DESCRIPTION OF “CAN DIAG SUPPORT
MNTR”SCREENFORINTELLIGENTKEYUNIT... 17
DESCRIPTION OF “CAN DIAG SUPPORT
MNTR” SCREEN FOR EPS CONTROL UNIT .... 17
DESCRIPTION OF “CAN DIAG SUPPORT
MNTR” SCREEN FOR BCM ............................... 18
DESCRIPTION OF “CAN DIAG SUPPORT
MNTR” SCREEN FOR ABS ACTUATOR AND
ELECTRIC UNIT (CONTROL UNIT) ................... 18
DESCRIPTION OF “CAN DIAG SUPPORT
MNTR” SCREEN FOR TCM ................................ 20
DESCRIPTION OF “CAN DIAG SUPPORT
MNTR” SCREEN FOR IPDM E/R ....................... 20
CAN COMMUNICATION ........................................... 21
System Description ................................................. 21
ComponentPartsandHarnessConnectorLocation... 21
LHD MODEL ....................................................... 21
RHD MODEL ....................................................... 22
Wiring Diagram — CAN — ..................................... 23
CR14DE/HR16DE MODEL ................................. 23
K9K MODEL ........................................................ 25
CAN Communication Unit ....................................... 27
TYPE 1/TYPE 2 ................................................... 28
TYPE 3/TYPE 4 ................................................... 30
TYPE 5/TYPE 6 ................................................... 32
TYPE 7/TYPE 8 ................................................... 34
TYPE 9/TYPE 10 ................................................. 36
CAN SYSTEM (TYPE 1) ........................................... 38
ComponentPartsandHarnessConnectorLocation... 38
Wiring Diagram — CAN — ..................................... 38
Check Sheet ........................................................... 38
Check Sheet ........................................................... 39
CHECK SHEET RESULTS (EXAMPLE) ............. 41
CAN SYSTEM (TYPE 2) ........................................... 51
ComponentPartsandHarnessConnectorLocation... 51
Wiring Diagram — CAN — ..................................... 51
Check Sheet ........................................................... 51
Check Sheet ........................................................... 52
CHECK SHEET RESULTS (EXAMPLE) ............. 54
CAN SYSTEM (TYPE 3) ........................................... 65
ComponentPartsandHarnessConnectorLocation... 65
Wiring Diagram — CAN — ..................................... 65
Check Sheet ........................................................... 65
Check Sheet ........................................................... 66
CHECK SHEET RESULTS (EXAMPLE) ............. 68
CAN SYSTEM (TYPE 4) ........................................... 79
ComponentPartsandHarnessConnectorLocation... 79
Wiring Diagram — CAN — ..................................... 79
Содержание
- Contents 1
- K electrical 1
- Lan system 1
- Sectio 1
- Check points for using consult ii 3
- Lhd models 3
- Maintenance information 3
- Precautions 3
- Precautions for supplemental restraint system srs air bag and seat belt pre tensioner 3
- Precautions when using consult ii 3
- Rhd models 3
- Can system 4
- Precautions 4
- Precautions for harness repair 4
- Precautions for trouble diagnosis 4
- Can communication line is open can h can l or both 5
- Can communication line is shorted ground between can lines or other harnesses 5
- Fuse blown out removed can communication of the unit may be stopped at such time 5
- Low voltage if the voltage decreases because of battery discharge when ignition switch is on malfunc tion may be detected by self diagnosis according to the units 5
- Removal and installation of parts when the units that perform can communication or the sensors related to can communication are removed and installed malfunction may be detected or dtc other than can communication may be detected 5
- The areas related to can communication of unit is malfunctioning 5
- Trouble diagnoses work flow 5
- When a malfunction is detected by can communication system 5
- When a malfunction is detected except can communication system 5
- When displaying can communication system errors 5
- Trouble diagnoses work flow 6
- Trouble diagnosis flow chart 6
- Determine can system type from the equipment of the vehicle to select applicable check sheet 7
- Diagnosis procedure 7
- Selecting can system type how to use specification table 7
- Trouble diagnoses work flow 7
- How to use check sheet table 9
- Trouble diagnoses work flow 9
- Example of filling in check sheet when initial conditions are reproduced 10
- Lan 10 10
- Trouble diagnoses work flow 10
- Confirm the unit name that unkwn is displayed on the copy of can diag support mntr screen of intelligent key eps bcm abs and ipdm e r as well as engine and then put a check mark to the check sheet table note 11
- For abs unkwn is displayed on ecm put a check mark to it 11
- For bcm unkwn is displayed on ecm put a check mark to it 11
- For eps unkwn is displayed on ecm put a check mark to it 11
- For intelligent key unkwn is displayed on ecm put a check mark to it 11
- For ipdm e r unkwn is displayed on ecm put a check mark to it 11
- Lan 11 11
- Trouble diagnoses work flow 11
- Lan 12 12
- Trouble diagnoses work flow 12
- Example of filling in check sheet when initial conditions are not reproduced 13
- For abs can comm circuit u1000 is displayed put a check mark to it 13
- For bcm can comm circuit u1000 is displayed put a check mark to it 13
- For engine can comm circuit u1001 is displayed put a check mark to it 13
- For eps can comm circuit u1000 is displayed put a check mark to it 13
- For intelligent key can comm circuit u1000 is displayed put a check mark to it 13
- For ipdm e r can comm circuit u1000 is displayed put a check mark to it 13
- Lan 13 13
- See self diag results of all units attached to the check sheet if can comm circuit can comm circuit u1000 or can comm circuit u1001 is displayed put a check mark to the appli cable column of self diagnostic results of the check sheet table note 13
- Trouble diagnoses work flow 13
- Lan 14 14
- Trouble diagnoses work flow 14
- Can diagnostic support monitor 15
- Description of can diag support mntr screen for ecm cr14de hr16de model 15
- Display results past 15
- Display results present 15
- Lan 15 15
- Trouble diagnoses work flow 15
- Display results past 16
- Display results present 16
- K9k model 16
- Lan 16 16
- Trouble diagnoses work flow 16
- Description of can diag support mntr screen for eps control unit 17
- Description of can diag support mntr screen for intelligent key unit 17
- Display results present 17
- Lan 17 17
- Trouble diagnoses work flow 17
- Description of can diag support mntr screen for abs actuator and elec tric unit control unit abs model 18
- Description of can diag support mntr screen for bcm 18
- Display results present 18
- Lan 18 18
- Trouble diagnoses work flow 18
- Display results past 19
- Display results present 19
- Esp model 19
- Lan 19 19
- Trouble diagnoses work flow 19
- Description of can diag support mntr screen for ipdm e r 20
- Description of can diag support mntr screen for tcm 20
- Display results present 20
- Lan 20 20
- Trouble diagnoses work flow 20
- Can communication 21
- Can controller area network is a serial communication line for real time application it is an on vehicle mul tiplex communication line with high data communication speed and excellent error detection ability many elec tronic control units are equipped onto a vehicle and each control unit shares information and links with other control units during operation not independent in can communication control units are connected with 2 communication lines can h line can l line allowing a high rate of information transmission with less wiring each control unit transmits receives data but selectively reads required data only 21
- Component parts and harness connector location 21
- Lan 21 21
- Lhd model 21
- System description 21
- Can communication 22
- Lan 22 22
- Rhd model 22
- Can communication 23
- Cr14de hr16de model 23
- Lan 23 23
- Wiring diagram can 23
- Can communication 25
- K9k model 25
- Lan 25 25
- Can communication 27
- Can communication unit 27
- Go to can system when selecting your car model from the following table 27
- Lan 27 27
- Model with esp 27
- Model with intelligent key system 27
- Note confirming the presence of the following items helps to identify can system type 27
- Can communication 28
- Input output signal chart 28
- Lan 28 28
- Type 1 28
- Type 1 type 2 system diagram 28
- Type 2 28
- Can communication 29
- Lan 29 29
- Can communication 30
- Input output signal chart 30
- Lan 30 30
- Type 3 30
- Type 3 type 4 system diagram 30
- Type 4 30
- Can communication 31
- Lan 31 31
- Can communication 32
- Input output signal chart 32
- Lan 32 32
- Type 5 32
- Type 5 type 6 system diagram 32
- Type 6 32
- Can communication 33
- Lan 33 33
- Can communication 34
- Lan 34 34
- Type 7 34
- Type 7 type 8 system diagram 34
- Type 8 34
- Can communication 35
- Input output signal chart 35
- Lan 35 35
- Can communication 36
- Input output signal chart 36
- Lan 36 36
- Type 10 36
- Type 9 36
- Type 9 type 10 system diagram 36
- Can communication 37
- Lan 37 37
- Can system type 1 38
- Check sheet 38
- Component parts and harness connector location 38
- Lan 38 38
- Wiring diagram can 38
- Can system type 1 39
- Check sheet 39
- Lan 39 39
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 39
- Can system type 1 41
- Case 1 41
- Check harness between data link connector and abs actuator and electric unit control unit refer to lan 179 inspection between data link connector and abs actuator and electric unit control unit circuit 41
- Check sheet results example 41
- Lan 41 41
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 41
- Can system type 1 42
- Case 2 42
- Lan 42 42
- Can system type 1 43
- Case 3 43
- Check data link connector circuit refer to lan 182 data link connector circuit inspection 43
- Lan 43 43
- Can system type 1 44
- Case 4 44
- Lan 44 44
- Can system type 1 45
- Case 5 45
- Check eps control unit circuit refer to lan 185 eps control unit circuit inspection 45
- Lan 45 45
- Can system type 1 46
- Case 6 46
- Lan 46 46
- Can system type 1 47
- Case 7 47
- Check abs actuator and electric unit control unit circuit refer to lan 186 abs actuator and electric unit control unit circuit inspection 47
- Lan 47 47
- Can system type 1 48
- Case 8 48
- Lan 48 48
- Can system type 1 49
- Case 10 49
- Case 9 49
- Check can communication circuit refer to lan 188 can communication circuit inspection 49
- Check ipdm e r ignition relay circuit continuously sticks off refer to lan 190 ipdm e r ignition relay circuit inspection 49
- Lan 49 49
- Can system type 1 50
- Case 11 50
- Lan 50 50
- Can system type 2 51
- Check sheet 51
- Component parts and harness connector location 51
- Lan 51 51
- Refer to lan 21 component parts and harness connector location 51
- Refer to lan 23 wiring diagram can 51
- Refer to lan 52 check sheet 51
- Wiring diagram can 51
- Can system type 2 53
- Lan 53 53
- Can system type 2 54
- Case 1 54
- Check sheet results example 54
- Lan 54 54
- Can system type 2 55
- Case 2 55
- Check ecm circuit refer to lan 180 ecm circuit inspection 55
- Lan 55 55
- Can system type 2 56
- Case 3 56
- Lan 56 56
- Can system type 2 57
- Case 4 57
- Check combination meter circuit refer to lan 184 combination meter circuit inspection 57
- Lan 57 57
- Can system type 2 58
- Case 5 58
- Lan 58 58
- Can system type 2 59
- Case 6 59
- Check eps control unit circuit refer to lan 185 eps control unit circuit inspection 59
- Lan 59 59
- Can system type 2 60
- Case 7 60
- Lan 60 60
- Can system type 2 61
- Case 8 61
- Check abs actuator and electric unit control unit circuit refer to lan 186 abs actuator and electric unit control unit circuit inspection 61
- Lan 61 61
- Can system type 2 62
- Case 9 62
- Lan 62 62
- Can system type 2 63
- Case 10 63
- Case 11 63
- Check can communication circuit refer to lan 188 can communication circuit inspection 63
- Check ipdm e r ignition relay circuit continuously sticks off refer to lan 190 ipdm e r ignition relay circuit inspection 63
- Lan 63 63
- Can system type 2 64
- Case 12 64
- Lan 64 64
- Can system type 3 65
- Check sheet 65
- Component parts and harness connector location 65
- Lan 65 65
- Refer to lan 21 component parts and harness connector location 65
- Refer to lan 23 wiring diagram can 65
- Refer to lan 66 check sheet 65
- Wiring diagram can 65
- Can system type 3 67
- Lan 67 67
- Can system type 3 68
- Case 1 68
- Check sheet results example 68
- Lan 68 68
- Can system type 3 69
- Case 2 69
- Check ecm circuit refer to lan 180 ecm circuit inspection 69
- Lan 69 69
- Can system type 3 70
- Case 3 70
- Lan 70 70
- Can system type 3 71
- Case 4 71
- Check combination meter circuit refer to lan 184 combination meter circuit inspection 71
- Lan 71 71
- Can system type 3 72
- Case 5 72
- Lan 72 72
- Can system type 3 73
- Case 6 73
- Check eps control unit circuit refer to lan 185 eps control unit circuit inspection 73
- Lan 73 73
- Can system type 3 74
- Case 7 74
- Lan 74 74
- Can system type 3 75
- Case 8 75
- Check abs actuator and electric unit control unit circuit refer to lan 186 abs actuator and electric unit control unit circuit inspection 75
- Lan 75 75
- Can system type 3 76
- Case 9 76
- Lan 76 76
- Can system type 3 77
- Case 10 77
- Case 11 77
- Check can communication circuit refer to lan 188 can communication circuit inspection 77
- Check ipdm e r ignition relay circuit continuously sticks off refer to lan 190 ipdm e r ignition relay circuit inspection 77
- Lan 77 77
- Can system type 3 78
- Case 12 78
- Lan 78 78
- Can system type 4 79
- Check sheet 79
- Component parts and harness connector location 79
- Lan 79 79
- Refer to lan 21 component parts and harness connector location 79
- Refer to lan 23 wiring diagram can 79
- Refer to lan 80 check sheet 79
- Wiring diagram can 79
- Can system type 4 81
- Lan 81 81
- Can system type 4 82
- Case 1 82
- Check sheet results example 82
- Lan 82 82
- Can system type 4 83
- Case 2 83
- Check ecm circuit refer to lan 180 ecm circuit inspection 83
- Lan 83 83
- Can system type 4 84
- Case 3 84
- Lan 84 84
- Can system type 4 85
- Case 4 85
- Check combination meter circuit refer to lan 184 combination meter circuit inspection 85
- Lan 85 85
- Can system type 4 86
- Case 5 86
- Lan 86 86
- Can system type 4 87
- Case 6 87
- Check steering angle sensor circuit refer to lan 185 steering angle sensor circuit inspection 87
- Lan 87 87
- Can system type 4 88
- Case 7 88
- Lan 88 88
- Can system type 4 89
- Case 8 89
- Check bcm circuit refer to lan 186 bcm circuit inspection 89
- Lan 89 89
- Can system type 4 90
- Case 9 90
- Lan 90 90
- Can system type 4 91
- Case 10 91
- Check ipdm e r circuit refer to lan 188 ipdm e r circuit inspection 91
- Lan 91 91
- Can system type 4 92
- Case 11 92
- Case 12 92
- Lan 92 92
- Can system type 4 93
- Case 13 93
- Check ipdm e r ignition relay circuit continuously sticks on refer to lan 190 ipdm e r ignition relay circuit inspection 93
- Lan 93 93
- Can system type 5 94
- Check sheet 94
- Component parts and harness connector location 94
- Lan 94 94
- Wiring diagram can 94
- Can system type 5 95
- Check sheet 95
- Lan 95 95
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 95
- Can system type 5 97
- Case 1 97
- Check harness between data link connector and abs actuator and electric unit control unit refer to lan 179 inspection between data link connector and abs actuator and electric unit control unit circuit 97
- Check sheet results example 97
- Lan 97 97
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 97
- Can system type 5 98
- Case 2 98
- Lan 98 98
- Can system type 5 99
- Case 3 99
- Check data link connector circuit refer to lan 182 data link connector circuit inspection 99
- Lan 99 99
- Can system type 5 100
- Case 4 100
- Lan 100 100
- Can system type 5 101
- Case 5 101
- Check eps control unit circuit refer to lan 185 eps control unit circuit inspection 101
- Lan 101 101
- Can system type 5 102
- Case 6 102
- Lan 102 102
- Can system type 5 103
- Case 7 103
- Check abs actuator and electric unit control unit circuit refer to lan 186 abs actuator and electric unit control unit circuit inspection 103
- Lan 103 103
- Can system type 5 104
- Case 8 104
- Lan 104 104
- Can system type 5 105
- Case 9 105
- Check ipdm e r circuit refer to lan 188 ipdm e r circuit inspection 105
- Lan 105 105
- Can system type 5 106
- Case 10 106
- Case 11 106
- Lan 106 106
- Can system type 5 107
- Case 12 107
- Check ipdm e r ignition relay circuit continuously sticks on refer to lan 190 ipdm e r ignition relay circuit inspection 107
- Lan 107 107
- Can system type 6 108
- Check sheet 108
- Component parts and harness connector location 108
- Lan 108 108
- Wiring diagram can 108
- Can system type 6 109
- Check sheet 109
- Lan 109 109
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 109
- Can system type 6 111
- Case 1 111
- Check harness between data link connector and abs actuator and electric unit control unit refer to lan 179 inspection between data link connector and abs actuator and electric unit control unit circuit 111
- Check sheet results example 111
- Lan 111 111
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 111
- Can system type 6 112
- Case 2 112
- Lan 112 112
- Can system type 6 113
- Case 3 113
- Check data link connector circuit refer to lan 182 data link connector circuit inspection 113
- Lan 113 113
- Can system type 6 114
- Case 4 114
- Lan 114 114
- Can system type 6 115
- Case 5 115
- Check intelligent key unit circuit refer to lan 184 intelligent key unit circuit inspection 115
- Lan 115 115
- Can system type 6 116
- Case 6 116
- Lan 116 116
- Can system type 6 117
- Case 7 117
- Check bcm circuit refer to lan 186 bcm circuit inspection 117
- Lan 117 117
- Can system type 6 118
- Case 8 118
- Lan 118 118
- Can system type 6 119
- Case 9 119
- Check tcm circuit refer to lan 187 tcm circuit inspection 119
- Lan 119 119
- Can system type 6 120
- Case 10 120
- Lan 120 120
- Can system type 6 121
- Case 11 121
- Case 12 121
- Check can communication circuit refer to lan 188 can communication circuit inspection 121
- Check ipdm e r ignition relay circuit continuously sticks off refer to lan 190 ipdm e r ignition relay circuit inspection 121
- Lan 121 121
- Can system type 6 122
- Case 13 122
- Lan 122 122
- Can system type 7 123
- Check sheet 123
- Component parts and harness connector location 123
- Lan 123 123
- Refer to lan 124 check sheet 123
- Refer to lan 21 component parts and harness connector location 123
- Refer to lan 23 wiring diagram can 123
- Wiring diagram can 123
- Can system type 7 125
- Lan 125 125
- Can system type 7 126
- Case 1 126
- Check sheet results example 126
- Lan 126 126
- Can system type 7 127
- Case 2 127
- Check ecm circuit refer to lan 180 ecm circuit inspection 127
- Lan 127 127
- Can system type 7 128
- Case 3 128
- Lan 128 128
- Can system type 7 129
- Case 4 129
- Check combination meter circuit refer to lan 184 combination meter circuit inspection 129
- Lan 129 129
- Can system type 7 130
- Case 5 130
- Lan 130 130
- Can system type 7 131
- Case 6 131
- Check bcm circuit refer to lan 186 bcm circuit inspection 131
- Lan 131 131
- Can system type 7 132
- Case 7 132
- Lan 132 132
- Can system type 7 133
- Case 8 133
- Check ipdm e r circuit refer to lan 188 ipdm e r circuit inspection 133
- Lan 133 133
- Can system type 7 134
- Case 10 134
- Case 9 134
- Lan 134 134
- Can system type 7 135
- Case 11 135
- Check ipdm e r ignition relay circuit continuously sticks on refer to lan 190 ipdm e r ignition relay circuit inspection 135
- Lan 135 135
- Can system type 8 136
- Check sheet 136
- Component parts and harness connector location 136
- Lan 136 136
- Wiring diagram can 136
- Can system type 8 137
- Check sheet 137
- Lan 137 137
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 137
- Can system type 8 139
- Case 1 139
- Check harness between data link connector and abs actuator and electric unit control unit refer to lan 179 inspection between data link connector and abs actuator and electric unit control unit circuit 139
- Check sheet results example 139
- Lan 139 139
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 139
- Can system type 8 140
- Case 2 140
- Lan 140 140
- Can system type 8 141
- Case 3 141
- Check data link connector circuit refer to lan 182 data link connector and can communication circuit inspection 141
- Lan 141 141
- Can system type 8 142
- Case 4 142
- Lan 142 142
- Can system type 8 143
- Case 5 143
- Check intelligent key unit circuit refer to lan 184 intelligent key unit circuit inspection 143
- Lan 143 143
- Can system type 8 144
- Case 6 144
- Lan 144 144
- Can system type 8 145
- Case 7 145
- Check bcm circuit refer to lan 186 bcm circuit inspection 145
- Lan 145 145
- Can system type 8 146
- Case 8 146
- Lan 146 146
- Can system type 8 147
- Case 9 147
- Check ipdm e r circuit refer to lan 188 ipdm e r circuit inspection 147
- Lan 147 147
- Can system type 8 148
- Case 10 148
- Case 11 148
- Lan 148 148
- Can system type 8 149
- Case 12 149
- Check ipdm e r ignition relay circuit continuously sticks on refer to lan 190 ipdm e r ignition relay circuit inspection 149
- Lan 149 149
- Can system type 9 150
- Check sheet 150
- Component parts and harness connector location 150
- Lan 150 150
- Wiring diagram can 150
- Can system type 9 151
- Check sheet 151
- Lan 151 151
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 151
- Can system type 9 153
- Case 1 153
- Check harness between data link connector and abs actuator and electric unit control unit refer to lan 179 inspection between data link connector and abs actuator and electric unit control unit circuit 153
- Check sheet results example 153
- Lan 153 153
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 153
- Can system type 9 154
- Case 2 154
- Lan 154 154
- Can system type 9 155
- Case 3 155
- Check data link connector circuit refer to lan 182 data link connector and can communication circuit inspection 155
- Lan 155 155
- Can system type 9 156
- Case 4 156
- Lan 156 156
- Can system type 9 157
- Case 5 157
- Check steering angle sensor circuit refer to lan 185 steering angle sensor circuit inspection 157
- Lan 157 157
- Can system type 9 158
- Case 6 158
- Lan 158 158
- Can system type 9 159
- Case 7 159
- Check bcm circuit refer to lan 186 bcm circuit inspection 159
- Lan 159 159
- Can system type 9 160
- Case 8 160
- Lan 160 160
- Can system type 9 161
- Case 9 161
- Check ipdm e r circuit refer to lan 188 ipdm e r circuit inspection 161
- Lan 161 161
- Can system type 9 162
- Case 10 162
- Case 11 162
- Lan 162 162
- Can system type 9 163
- Case 12 163
- Check ipdm e r ignition relay circuit continuously sticks on refer to lan 190 ipdm e r ignition relay circuit inspection 163
- Lan 163 163
- Can system type 10 164
- Check sheet 164
- Component parts and harness connector location 164
- Lan 164 164
- Wiring diagram can 164
- Can system type 10 165
- Check sheet 165
- Lan 165 165
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 165
- Can system type 10 167
- Case 1 167
- Check harness between data link connector and abs actuator and electric unit control unit refer to lan 179 inspection between data link connector and abs actuator and electric unit control unit circuit 167
- Check sheet results example 167
- Lan 167 167
- Note if a check mark is put on ng on initial diag initial diagnosis replace the control unit 167
- Can system type 10 168
- Case 2 168
- Lan 168 168
- Can system type 10 169
- Case 3 169
- Check data link connector circuit refer to lan 182 data link connector and can communication circuit inspection 169
- Lan 169 169
- Can system type 10 170
- Case 4 170
- Lan 170 170
- Can system type 10 171
- Case 5 171
- Check intelligent key unit circuit refer to lan 184 intelligent key unit circuit inspection 171
- Lan 171 171
- Can system type 10 172
- Case 6 172
- Lan 172 172
- Can system type 10 173
- Case 7 173
- Check eps control unit circuit refer to lan 185 eps control unit circuit inspection 173
- Lan 173 173
- Can system type 10 174
- Case 8 174
- Lan 174 174
- Can system type 10 175
- Case 9 175
- Check abs actuator and electric unit control unit circuit refer to lan 186 abs actuator and electric unit control unit circuit inspection 175
- Lan 175 175
- Can system type 10 176
- Case 10 176
- Lan 176 176
- Can system type 10 177
- Case 11 177
- Case 12 177
- Check can communication circuit refer to lan 182 data link connector and can communication circuit inspection 177
- Check ipdm e r ignition relay circuit continuously sticks off refer to lan 190 ipdm e r ignition relay circuit inspection 177
- Lan 177 177
- Can system type 10 178
- Case 13 178
- Lan 178 178
- Inspection between data link connector and abs actuator and electric unit control unit circuit 179
- Lan 179 179
- Trouble diagnosis for system 179
- Ecm circuit inspection 180
- Lan 180 180
- Trouble diagnosis for system 180
- Check harness for open circuit 181
- Cr14de model 1 disconnect ecm connector 2 check resistance between ecm harness connector terminals 181
- Hr16de model 1 disconnect ecm connector 2 check resistance between ecm harness connector terminals 181
- K9k model 1 disconnect ecm connector 2 check resistance between ecm harness connector terminals 181
- Lan 181 181
- Ok or ng 181
- Repair harness between ecm and data link connector 181
- Trouble diagnosis for system 181
- Data link connector and can communication circuit inspection 182
- Data link connector circuit inspection 182
- Lan 182 182
- Trouble diagnosis for system 182
- Lan 183 183
- Trouble diagnosis for system 183
- Combination meter circuit inspection 184
- Intelligent key unit circuit inspection 184
- Lan 184 184
- Trouble diagnosis for system 184
- Eps control unit circuit inspection 185
- Lan 185 185
- Steering angle sensor circuit inspection 185
- Trouble diagnosis for system 185
- Abs actuator and electric unit control unit circuit inspection 186
- Bcm circuit inspection 186
- Lan 186 186
- Trouble diagnosis for system 186
- Lan 187 187
- Tcm circuit inspection 187
- Trouble diagnosis for system 187
- Can communication circuit inspection 188
- Ipdm e r circuit inspection 188
- Lan 188 188
- Trouble diagnosis for system 188
- Lan 189 189
- Trouble diagnosis for system 189
- Ipdm e r ignition relay circuit inspection 190
- Lan 190 190
- Trouble diagnosis for system 190
Похожие устройства
- Nissan Note LIGHTING SYSTEM
- Daikin BRC1H81W7 Инструкция по эксплуатации
- Nissan Note REAR AXLE
- Nissan Note REAR SUSPENSION
- Nissan Note POWER STEERING SYSTEM
- Nissan Note SEAT
- Nissan Note STEERING CONTROL SYSTEM
- Nissan Note MANUAL TRANSAXLE
- Nissan Note MAINTENANCE
- Daikin BRC1H81W7 Руководство по применению для установщика
- Nissan Note SUPPLEMENTAL RESTRAINT SYSTEM _SRS_
- Nissan Note STARTING _ CHARGING SYSTEM
- Nissan Note POWER SUPPLY, GROUND _ CIRCUIT ELEMENTS
- Nissan Note ROAD WHEELS _ TYRES
- Nissan Note WIPER, WASHER _ HORN
- Daikin BRC1H81S7 Инструкция по эксплуатации
- Daikin BRC1H81S7 Руководство по применению для установщика
- Daikin BRC1H82W Инструкция по эксплуатации
- Daikin BRC1H82W Руководство по применению для установщика
- Daikin BRC1H82K Инструкция по эксплуатации
Скачать
Случайные обсуждения
