![Nissan Note [11/12] Rsu 11](/views2/1789824/page11/bgb.png)
SERVICE DATA AND SPECIFICATIONS (SDS)
RSU-11
C
D
F
G
H
I
J
K
L
M
A
B
RSU
SERVICE DATA AND SPECIFICATIONS (SDS) PFP:00030
Wheel Alignment
BES00036
Tightening Torque
BES00037
Unit: N·m (kg-m)
Camber -1°55′ --0°25′ (-1.92° - -0.42°)
Toe-in In0-8mm(0-0.31in)
Shock absorber piston rod lock nut 20 (2.0, 15)
Rear suspension beam to rear suspension arm bracket 160 (16, 118)
Shock absorber to rear suspension beam 90 (9.2, 66)
Rear suspension arm bracket to body 50 (5.1, 37)
